TECHNICAL  DATA

 8.  CE DECLARATION OF CONFORMITY

 7.  TECHNICAL DATA

                                                                                                           DP700

                                                                                220-240V~50 Hz

                                                                                                     710W

                                                                         0-2800/min

                                                                                          13 mm

                                                                                                        2 kg

                                                                                                          25 mm

                                                                                                         13 mm

13 mm

Model

Operating power

Capacity

Idle rotation speed n

O

Chuck capacity

Weight

Maximum drilling depth:

  Wood

  Steel

  Concrete

CE DECLARATION OF CONFORMITY

                                                                                                                                                                           Caron Giacinto

                                                                                                                                                                                  Director

                                                                                                                                                                       STATUS ITALIA S.R.L.

Noise and vibration information

Noise emission (measured values determined according to EN 60745):

A-weighted sound pressure level                              L

pA

 94 dB(A)  Uncertainty К

pA

 3.0 dB

A-weighted sound power level                               L

wA

 105 dB(A)  Uncertainty К

wA

 3.0 dB

Wear hearing protection!

Vibration emission

Total vibration values (vector sum in the three axes)

determined according to EN 60745

Vibration emission value

                                       a

h

ID

9 m/s²   Uncertainty K1.5 m/s²

 6. CARE  AND  MAINTENANCE

 8

EN

 9

EN

• Hold the machine securely at all times.

• Always keep one finger on the on/off button to be able to turn it off quickly.

For long duration operation, you can push the lock-on button (5) once.

The on/off button (3) must be pressed for this. The machine will stay on until the on/off

button is pushed quickly once again.

Setting the rotation speed

By pressing the on/off button (3), you can set the rotation speed during idle operation.

The optimal rotation speed depends on the material drilled, the operation mode, and the

inserted drill.

Light pressure on the on/off button: low rotation speed

Greater pressure on the on/off button: higher rotation speed

Selecting the rotation direction

• Do not set the left/right rotation switch during drilling.

• The rotation direction is always according to the switch position.

• Switch position R: right-rotation/forward/clockwise.To drill and to screw in screws,

  push the right/left rotation switch (2) all the way to the right.

• Switch position L: left-rotation/backward/counter-clockwise. To loosen or pull out

  screws and nuts, push the right/left rotation switch (2) to the left until the stopper.

Cooling the motor

If the motor has intensely overheated, allow it to run idle for 2 to 3

minutes on maximum rotation speed.

CARE  AND  MAINTENANCE

WARNING:

Always ensure that the tool is switched off and unplugged before attempting

to perform inspection or maintenance.

BRUSH REPLACEMENT

When the carbon brushes are worn out, brushes must be

replaced simultaneously with genuine brushes at STATUS service centre for warranty

and post-warranty service.

GENERAL INSPECTION

Regularly inspect all fasteners and ensure they are properly

tightened. Should any of the screws be loose, retighten it immediately to avoid hazards.

If the replacement of the supply cord is necessary, this has to be done by the manufac-

turer or his agent in order to avoid a safety hazard.

CLEANING

For safe operation always keep the machine and its ventilation slots clean.

Regularly check to see if any dust or foreign matter has entered the ventilation slots and

the grills around the switches. Use a soft brush and/or air jet to remove any accumulated

dust. Wear safety glasses to protect your eyes whilst cleaning. Exterior plastic parts may

be cleaned with a damp cloth and mild detergent if necessary.

WARNING:

Never use alcohol, petrol or other cleaning agent. Never use caustic agents

 to clean plastic parts.

WARNING:

Water must never come into contact with the tool.

IMPORTANT!

To assure product safety and reliability, repairs, maintenance and adjust-

ment (including brush inspection

and replacement) should be performed by certified

service centres or other qualified service organisations, always using genuine replace-

ment parts.

ATTENTION!

The consumer can independently replace only the drill chuck on this product.

We STATUS ITALIA S.R.L. as the responsible manufacturer declare that the

following STATUS machine(s): Impact Drill Model No./ Type: DP700 are of series

production and сonforms to the following European Directives:

Directive 2006/42/EC, Directive 2011/65/EU, EMC Directive 2014/30/EU.

And are manufactured in accordance with the following standards or standardised

documents:

EN 60745-1:2009/A11:2010, EN 60745-2-1:2010, EN 55014-1:2006,

EN 55014-2:1997/A2:2008, EN 61000-3-2:2014, EN 61000-3-3:2013.

The technical documentation kept by the manufacturer: STATUS ITALIA S.R.L.,

via Aldo Moro, 14/A, 36060 - Pianezze (VI), ITALY
