SAFETY  ADVICE

•

Maintain power tools. Check for misalignment or binding of moving parts,

breakage of parts and any other condition that may affect the power tools

operation. If damaged, have the power tool repaired before use.

Many

accidents are caused by poorly maintained power tools.

•

Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp

 cutting edges are less likely to bind and easier to control.

•

Use the power tool, accessories and tool bits etc., in accordance with these

instructions and in the manner intended for the particular type of power tool,

taking into account the working conditions and the work to be performed.

Use of the power tool for operations different from intended could result in a

hazardous situation.

5) SERVICE

•

Have your power tool serviced by a qualified repair person using only identical

replacement parts.

This will ensure that the safety of the power tool is

maintained.

Additional safety instructions for your electric drill

•

Do not use the electric power tool with a damaged cable. Do not move the

damaged cable, and pull out the power plug if the cable becomes damaged

during operation.

Damaged cables increase the risk of electric shock.

•

If the replacement of the supply cord is necessary, this has to be done by the

manufacturer or his agent in order to avoid a safety

hazard.

•

Materials containing asbestos may not be worked on.

Fine dust particles can

remain in the air, despite the installation of a dust vacuum, and can greatly

endanger your health.

 6

3

.

PARTS  AND  ACCESSORIES

4

.

PRIOR  TO  FIRST  USE

PARTS  AND  ACCESSORIES

PRIOR  TO  FIRST  USE

1

.  Chuck

 2.

Left/right rotation switch L/R

 3.

On/off button

4

.  Variable speed dial

5

.  Lock-on button

 6.  Auxiliary handle
 7.  Depth gauge
 8.  Changeover switch
 9.  Gear selection switch
10. Rotating button
11. Stopper adjuster

Danger of injury!

Before all adjustments and settings:

•

Turn the machine off.

•

Wait until the machine has come to a complete standstill.

•

Pull out the power plug.

Remove the packaging and make sure that all parts are there.

Installing side grip (auxiliary handle)

Always use the side grip to ensure operating safety.
•

Install the side grip on tool barrel.

• Then tighten the grip by turning clockwise rotating button (10) securely at the


desired position. It may

be

sw

i

ng 360° so as to be secured at any position.

Depth gauge

The depth gauge is convenient for drilling holes of uniform depth.

• Press the depth stopper adjuster (11) and insert the depth gauge into the hole in


the side grip.

•

Adjust the depth gauge to the desired depth and

losen the stopper adjuster (11)

.

Inserting the drill

•

Place the drill socket key in one of the side holes of the drill socket and turn the

drill socket

clockwise.

•

Select a designated drill and push it as far as possible into the drill socket

opening.

•

Tighten the drill socket by turning it counter-clockwise. Make sure that the drill

 is secure in

 the drill socket.

•

Conduct a short test-run and make sure that the drill is tightly secured even

after a complete run.

Using screw tools

When using screw bits, you should always use a universal bit holder.
Only use screw bits which are compatible with the screw head.
