5

ENGLISH

(Original instructions)

Electrical safety

This tool is double insulated; therefore no earth

wire is required. Always check that the power

supply corresponds to the voltage on the rating

plate.

•  If the supply cord is damaged, it must be replaced by the

manufacturer or an authorised STANLEY Service Centre

in order to avoid a hazard.

Using an extension cable

•  Always use an approved extension cable suitable for the

power input of this tool (see technical data). Before use,

inspect the extension cable for signs of damage, wear

and ageing. Replace the extension cable if damaged or

defective. When using a cable reel, always unwind the

cable completely. Use of an extension cable not suitable

for the power input of the tool or which is damaged or

defective may result in a risk of fire and electric shock.

Features

This tool includes some or all of the following features.
1.  Variable speed switch
2.  Lock-on button
3.  Forward/reverse slider
4. Chuck
5. Sleeve
6.  Bit Shaft
7.  Speed dial
8. Hole
9.  Speed dial

Assembly

Warning! Before assembly, make sure that the tool is

switched off and unplugged.
Keyed chuck (fig. B)
•  Open the chuck by turning the sleeve (5)

counterclockwise.

•  Insert the bit shaft (6) into the chuck.
•  Insert the chuck key (7) into each hole (8) in the side of

the chuck and turn clockwise until tight.

Removing and refitting the chuck (fig. C)
•  Open the chuck as far as possible.

•  Remove the chuck retaining screw, located in the chuck,

  by turning it clockwise using a screwdriver.
•  Tighten an Allen key into the chuck and strike it with a

hammer as shown.

•  Remove the Allen key.
•  Remove the chuck by turning it counterclockwise.
•  To refit the chuck, screw it onto the spindle and secure it

with the chuck retaining screw.

Use

Warning! Let the tool work at its own pace. Do not overload.
Warning! Before drilling into walls, floors or ceilings, check

for the location of wiring and pipes.
Selecting the direction of rotation (fig. D)
For drilling and for tightening screws, use forward

(clockwise) rotation. For loosening screws or removing a

jammed drill bit, use reverse (counterclockwise) rotation.
•  To select forward rotation, push the forward/reverse

slider (3) to the left position.

•  To select reverse rotation, push the forward/reverse

slider to the right.

Viewed when holding the drill in the operating position. After

any reversing operations, return slider (3) to forward

position.
Warning! Never change the direction of rotation while the

motor is running.
Switching on and off
•  To switch the tool on, press the variable speed switch

(1). The tool speed depends on how far you press the

switch.

•  For continuous operation, press the lock-on button (2)

and release the variable speed switch. This option is

available only at full speed.

•  To switch the tool off, release the variable speed switch.

To switch the tool off when in continuous operation, press

the variable speed switch once more and release it.

•  Based on the different applications, turn around the

speed dial (9) to control the maximum speed.

Proper Hand Position (fig.E)

Warning! To reduce the risk of serious personal

injury, ALWAYS use proper hand position as

shown in figure E.
