8

ENGLISH

(Original instructions)

Adjusting the screwdrive bit depth (Fig. G)

It is important to control the depth to which the drywall screw

will be driven. Over driving the screw will drive the screw too

deep and break the outer paper layer of the drywall. Under

driving the screw will leave the screw head above the

drywall surface making it impossible to properly finish the

drywall.

The depth control system is made up of the depth stop (1)

and the depth adjuster (2).

Warning!

 The following adjustments should always

be verified using a scrap piece of drywall to avoid

damaging the “good” drywall sections.

1.  Rotate the depth adjuster counter clockwise until

approximately 1/4” of the screwdriver bit extends beyond

the depth stop.

2.  Place a drywall screw onto the screwdriver bit. The

magnetized bit will hold the screw onto the bit.

Note:

Before driving the screw, press the screw point into

the drywall and make sure the screw is perpendicular to the

drywall.

3.  Press the screw against the drywall with steady even

pressure and squeeze the trigger switch. The clutch in

the tool will engage and the screw will be driven to the

preset depth.

4.  If the screw is not driven deep enough, the head of the

screw will not be recessed into the drywall (Fig. H). In

this case, turn the depth adjustment sleeve clockwise

until the correct depth has been achieved. If the screw is

driven too deep, it will be recessed too far into the

drywall and the outer paper of the drywall will be

fractured (Fig. I). In this case, turn the depth adjustment

sleeve counter clockwise until the correct depth has

been achieved. Fig. J illustrates the correct depth for the

screw to be driven.

Note:

 For each revolution the depth adjustment sleeve is

rotated, the depth will increase/decrease approximately

1/16” (1.6 mm).

Tips for driving drywall screws

ff Always drive the screws perpendicular to the drywall so

the heads are properly countersunk. They should never be

driven at an angle.

•  Support the tool with both hands wherever possible.

This will provide better control over the tool help

eliminate screws being driven at an angle.

•  Place the drywall screw on the screwdriver bit. The

magnetic bit holder will hold any steel screw for easy

starting.

•  Press the screw against the drywall with steady even

pressure and squeeze the variable speed trigger switch.

The clutch in the tool will engage and the screw will be

driven to the preset depth. Once fully driven, the clutch

will make a chattering sound until the variable speed

trigger is released.

•  When the screw is properly driven, the screw head will

be slightly countersunk into the drywall without breaking

the outer drywall paper. At this point, the clutch will

release to prevent over driving the screw. This will result

in minimum work to fill the holes and taping the seams.

•  The belt clip allows you to conveniently attached the

screwdriver to your belt. This will allow you to use both

hands for positioning the drywall.

Removing drywall screws (Fig. K)

To remove drywall screws, remove the depth stop (1) to

expose the screwdriver bit.

Notes:

a.  The depth stop is a press fit onto the depth adjuster (2).

Simply twist and pull outward to slide it off the depth

adjuster.

b.  You can also turn the depth adjuster clockwise to expose

the screwdriver bit. This however will cause you to lose

the depth setting and you will have to re-set the depth.

Maintenance

Keep guards, air vents and the motor housing as clear as

possible of dust and dirt. Wipe with a clean cloth and blow

through with a low-pressure air supply. Excessive build-up of

metal dust can cause tracking of electrical current from the

internal parts to exposed metal parts. Do not overload your

angle grinder. Overloading causes a reduction in speed and

efficiency, causing your angle grinder to become too hot. If

this happens, operate your angle grinder under no load for

one or two minutes until it has cooled to normal operating

temperature. Switching your angle grinder off under load will

reduce the life of the switch.
