ENGLISH

(Original instructions)

6

NOTE:

 Large [5/16” (8 mm) to 1/2” (13 mm)] holes in steel

can be made easier if a pilot hole [5/32” (4 mm) to 3/16” (5

mm)] is drilled first.

Drilling in wood

Start drilling with slow speed and increase to full power

while applying firm pressure on the tool. Holes in wood can

be made with the same twist drills used for metal. These

bits may overheat unless pulled out frequently to clear

chips from the flutes. Work that is apt to splinter should be

backed up with a block of wood.

Drilling in masonry

When drilling in masonry, use carbide-tipped bits rated for

Impact drilling and be certain that the bits are sharp. Use a

constant and firm force on the tool to drill most effectively.

A smooth, even flow of dust indicates the proper drilling

rate.

Screwdriving

Select forward or reverse rotation.

Accessories

The performance of your tool depends on the accessory

used. STANLEY accessories are engineered to high quality

standards and designed to enhance the performance of

your tool. By using these accessories you will get the very

best from your tool.

Maintenance

Your tool has been designed to operate over a long period

of time with a minimum of maintenance. Continuous

satisfactory operation depends upon proper tool care and

regular cleaning.

Warning!

 Before performing any maintenance, switch off

and unplug the tool.

♦

Regularly clean the ventilation slots in your tool using a

soft brush or dry cloth.

♦

Regularly clean the motor housing using a damp cloth.

Do not use any abrasive or solvent-based cleaner.

Protecting the environment

Separate collection. This product must not be

disposed of with normal household waste.
Should you find one day that your STANLEY

product needs replacement, or if it is of no further use to

you, do not dispose of it with household waste. Make this

product available for separate collection.

Separate collection of used products and packag-

ing allows materials to be recycled and used

again. Re-use of recycled materials helps prevent

environmental pollution and reduces the demand

for raw materials.

Local regulations may provide for separate collection of

elec trical products from the household, at municipal waste

sites or by the retailer when you purchase a new product.
STANLEY  provides a facility for the collection and

recycling of STANLEY products once they have reached

the end of their working life. To take advantage of this

service please return your product to any authorised repair

agent who will collect them on our behalf.
You can check the location of your nearest authorised

repair agent by contacting your local STANLEY office at

the address indicated in this manual. Alternatively, a list

of authorised STANLEY repair agents and full details of

our after-sales service and contacts are available on the

Internet at: www.2helpU.com

Notes

♦

STANLEY’s policy is one of continuous improvement

to our products and as such, we reserve the right to

change product specifications without prior notice.

♦

Standard equipment and accessories may vary by

country.

♦

Product specifications may differ by country.

♦

Complete product range may not be available in all

countries. Contact your local STANLEY dealers for

range availability.

Technical data

SDH600

SDH700

Input voltage

V

AC

220-240

220-240

Power input

W

600

700

Frequency

Hz

50/60

50/60

No-load speed

min

-1

0-2900

0-2900

Impact rate

ipm

49300

49300

Chuck capacity

mm

1.5-13

1.5-13

Max.Drilling Capacity
Concrete/Metal/

Wood

mm

 13/13/25

 13/13/30

Weight

kg

1.75

1.87
