ENGLISH

en

14

Vacuum or wash protective clothing. Do not blow,

beat or brush.

Illustrations are provided at the beginning of the

operating instructions.

Symbol explanation:

 Normal drilling/Drill bit

 Impact drilling

 Movement direction

 Driving screws/Screw
 Slow
 Fast

Fig. A

1 Thumb-wheel for gear selection

2 Additional handle/Additional handle with

vibration damping *

3 Depth  stop

4 Geared  chuck  *

5 Futuro Plus keyless chuck *

6 Futuro Top keyless chuck *

7 Sliding switch (normal drilling/impact drilling)

8 Speed preselection wheel *

9 Setting wheel for impulse function *

10 Electronic signal indicator *

11 Rotation selector switch *

12 Lock button for continuous activation

13 Trigger

* depending on model

Before plugging in the device, check to see

that the rated mains voltage and mains

frequency, as specified on the rating label, match

your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.
To guarantee secure purchase of the chuck:

After initial drilling (clockwise), use a screw-

driver to firmly tighten the safety screw inside the

drill chuck (if available/depending on the model).

THE SAFETY SCREW HAS A LEFT-HANDED

THREAD!

7.1 Fitting the additional handle (2)

Fig.

B

For safety reasons, always use the additional

handle supplied.

Tighten the additional handle firmly by turning it.

8.1

Setting depth stop

Fig. C

8.2 Setting direction of rotation, transporting

safety device (switch-on lock)

Fig. D

Do not activate the rotation selector switch

(11) unless the motor has completely stopped.

8.3 Setting for normal drilling, impact drilling

Fig. E

Impact drilling and normal drilling only in a

clockwise direction.

8.4 Selecting gear

Fig. F

Change thumbwheel (1) only when the

machine is in the process of running down

(briefly switch it on and off).

8.5 Setting impulse function

Fig. G

= impulse function switched on constantly (to

facilitate tightening and releasing of screws

that are tight even when the screw heads are

damaged. To enable clean drilling without

centre punching in tiles, aluminium or other

materials).

8.6 Preselecting rotational speed

Fig. H

See the table for recommended rotational speeds

for drilling.

8.7 Switching On and Off

Switching on, rotational speed

Fig. A

: Press

the trigger (13).
Release the trigger to switch off.

Continuous operation

Fig. A

: With the trigger

(13) pressed, push in the locking button (12) and

release the trigger. Press and release the trigger

(13) again to switch off.

In continuous operation, the machine

continues running if it is forced out of your

hands. Therefore, always hold the machine with

both hands using the handles provided, stand in a

safe position and concentrate.

8.8 Tool change, Futuro Top keyless chuck

(6)

Fig. I

Clamp the tool by turning the sleeve firmly to its

stop.

8.9 Tool change, Futuro Plus (5) keyless

chuck

Fig. J

The ratchet sound which can possibly be heard

after opening the drill chuck is functional and is

switched off by a reverse rotation of the sleeve.
If the chuck is very tightly closed: Firmly grip the

chuck with an open-end spanner at the chuck head

and firmly turn the sleeve in the direction of the

arrow -1.
Clamping the tool
- Insert the tool -2- as far as possible.

- Using one hand, hold the retainer ring securely

(depending on fittings).

- Turn sleeve in direction -3- until the noticeable

mechanical resistance has been overcome.

5. Figures

6. Overview

7. Initial Operation

8. Use
