ENGLISH

en

13

Cleaning:

 from time to time, hold the machine

vertically with the chuck facing downwards and
turn the sleeve fully in the direction "GRIP, ZU"
and then turn fully in the direction
"AUF, RELEASE". The dust collected falls from
the keyless chuck.

7.9

Unscrewing the chuck

Fig. H

Employ the same procedure when attaching the
chuck, except in reverse order.

7.10 Chuck with quick-change system Quick

(for machines with the designation ...BL

Q...)

Fig. I

Removal:

 push the interlock ring forward (a), pull

off the chuck forwards (b).

To fit:

 push the interlock ring forward and move the

chuck as far as the limit stop on the drill spindle.

7.11 Fitting the belt hook (equipment-

specific) / bit depot (equipment-specific)

Fig. J

Fit the belt hook (7) as shown.
Fit the bit depot (6) as shown.

8.1

The machine's multifunctional

monitoring system

If the machine switches off automatically, the
machine electronics have activated automatic

protection mode. A warning signal sounds
(continuous beeping). The beeping stops after a
maximum of 30 seconds or when the trigger switch
(14) is released.

In spite of this protective function, overloading
is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost empty

Fig. A, B

(The

electronics protect the battery pack against
damage through total discharge).
If one LED (10) is flashing, the battery pack is
almost flat. If necessary, press the button (9) and
check the LED lamps (10) to see the charge
level. If the battery pack is almost flat, it must be
recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

Leave the machine or battery pack to cool.
Note: if the battery pack feels very warm, the
pack will cool more quickly in an "AIR COOLED"
charger.
Note: the machine will cool more quickly if you
operate it at idling speed.

3. Metabo

Safety shut-down

: The machine has

SHUT DOWN by itself. If the speed suddenly
drops (for example, if the machine suddenly
seizes or kickback occurs), the machine
switches off. Switch off the machine at the
trigger switch (14). Switch it on again and

continue to work as normal. Try to prevent the
machine from seizing.

8.2

Note:

The LED lamp (13) switches off automatically after
a specific time.

Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Fit accessories securely. If the machine is operated
in a holder: secure the machine well. Loss of control
can cause personal injury.
For a complete range of accessories, see
www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be
carried out by qualified electricians!

Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.

Do not allow battery packs to come into contact with
water!

Protect the environment, and do not dispose
of power tools and battery packs with house-
hold waste. Observe national regulations on

separated collection and recycling of disused
machines, packaging and accessories.
Discharge the battery pack in the power tool before
disposal. Prevent the contacts from short-circuiting
(e.g. by protecting them with adhesive tape).

Fig. K.

We reserve the right to make technical

improvements.
U

=

Voltage of battery pack

n

0

 =

No-load

speed

Tightening torque for screwing:
M

1

=

Soft screwing application (wood)

M

2

=

Pulse  torque

M

3

=

Hard screwing applications (metal)

M

4

=

Adjustable torque

Max. drill diameter:
D

1 max

=

in steel

D

2 max

=

in softwood

D

3 max

=

in masonry

s

=

Max.  impact  rate

m

=

Weight (with the smallest battery pack)

G

=

Spindle  thread

D

 max

=

Chuck clamping range

8. Troubleshooting

9. Accessories

10. Repairs

11. Environmental Protection

12. Technical Data
