ENGLISH
en
12
Reduce dust exposure with the following measures:
- do not direct the escaping particles and the
exhaust air stream at yourself or nearby persons
or on dust deposits.
- use an extraction unit and/or air purifiers.
- ensure good ventilation of the workplace and keep
clean using a vacuum cleaner. Sweeping or
blowing stirs up dust.
- Vacuum or wash the protective clothing. Do not
blow, beat or brush.
Illustrations are provided at the beginning of the
operating instructions.
Symbol explanation:
Movement direction
Drill bit
Slow
Fast
First gear
Second gear
Screws
Drills, screws, threaded rods
Impact drilling
Torque
Fig. A
1 Keyless chuck
2 Additional handle
3 Slide switch (normal drilling, impact drilling) *
4 Gear switch
5 Rotation selector switch (rotation setting,
transport lock) - both sides of the machine
6 Bit depot *
7 Belt hook *
8 Battery pack release button
9 Capacity indicator button
10 Capacity and signal indicator
11 Battery pack
12 Setting wheel for
- Pulse function
- Torque control
- max. torque
13 LED light
14 Trigger switch
*equipment-specific
7.1
Battery pack, capacity and signal
indicator
Fig. B
Charge the battery pack before use.
Recharge the battery pack if performance dimin-
ishes.
The ideal storage temperature is between 10°C and
30°C.
7.2
Removing and inserting the battery pack
Fig. C
7.3
Setting the direction of rotation,
engaging the transporting safety device
(switch-on lock)
Fig. D
7.4
Select the gear
Fig. E
Do not set the gear switch (4) unless the motor
has stopped completely!
7.5
Set drill, hammer drill
Fig. A
Activate slide switch (3).
7.6
Setting torque control, maximum torque,
pulse function
Do not work for long periods with pulse
function switched on! (The motor can
overheat.)
Fig. F
Set the desired operating mode at the setting wheel
(12):
1...10 = Torque
control
= maximum
torque
= Pulse
function
7.7
Switching On/Off, setting the speed
Fig. A
Switching on, speed:
press the trigger switch (14)
. Press in the trigger switch to increase the
rotational speed.
Switching off:
release the trigger switch (14). Note:
the noise that the machine makes when it
switches off is due to the design (quick stop)
and has no influence on the function or the
service life of the machine.
7.8
Keyless chuck
Fig. G
With a soft tool shank, retightening may be required
after a short drilling period.
Instructions for machines with the designation
SB...:
1. The grating sound which may be heard after
opening the chuck is functional and is stopped
by turning the sleeve in the opposite direction.
2. Clamping the tool:
Turn sleeve in direction "GRIP, ZU" until the
noticeable mechanical resistance has been
overcome.
Caution! The tool is not yet clamped!
Keep
turning the sleeve (
it must "click" when
turning
), until it cannot be turned any further -
only now
is the tool
securely
clamped.
5. Figures
6. Overview
7. Use
Nm
