ENGLISH

en

13

7.7 Keyless chuck

Fig. G

With a soft tool shank, retightening may be required

after a short drilling period.

Information for machines with the designation

BS 18 LT BL, SB 18 LT BL:

1. The grating sound which may be heard after

opening the chuck is functional and is stopped

by turning the sleeve in the opposite direction.

2. Clamping the tool:

Turn sleeve in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The tool is not yet clamped!

 Keep

turning the sleeve (

it must "click" when

turning

), until it cannot be turned any further -

only now

 is the tool

 securely

 clamped.

Cleaning:

 from time to time, hold the machine

vertically with the chuck facing downwards and

turn the sleeve fully in the direction "GRIP, ZU"

and then turn fully in the direction

"AUF, RELEASE". The dust collected falls from

the keyless chuck.

7.8 Unscrewing the chuck

Fig. H

Employ the same procedure when attaching the

chuck, except in reverse order.

7.9 Chuck with quick change system (with

BS 18 LT BL Q)

Fig. I

To remove:

 push the interlock ring forward (a),

advance and pull off the chuck forwards (b).

To fit:

 push the interlock ring forward and move the

chuck as far as the limit stop on the drill spindle.

7.10 Fitting the belt hook (equipment-

specific) / bit depot (equipment-specific)

Fig. J

Fit the belt hook (7) as shown.

Fit the bit depot (6) as shown.

8.1 The machine's multifunctional

monitoring system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. A warning signal sounds

(continuous beeping). The beeping stops after a

maximum of 30 seconds or when the trigger switch

(13) is released.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost empty

Fig. A, B

(The

electronics protect the battery pack against

damage through total discharge).

If one LED (10) is flashing, the battery pack is

almost flat. If necessary, press the button (9) and

check the LEDs (10) to see the charge level. If

the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

Leave the machine or battery pack to cool.
Note: if the battery pack feels very warm, the

pack will cool more quickly in an "AIR COOLED"

charger.
Note: the machine will cool more quickly if you

operate it at idling speed.

3. Metabo

safety shutdown

: the machine has

SHUT DOWN by itself. If the speed suddenly

drops (for example, if the machine suddenly

seizes or kickback occurs), the machine

switches off. Switch off the machine at the

trigger switch (13). Switch it on again and

continue to work as normal. Try to prevent the

machine from seizing.

Only use original Metabo battery packs and Metabo

accessories.
Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.
Fitting the angle drilling attachment

Fig. K

.

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

Contact your local Metabo representative if you

have Metabo power tools requiring repairs. See

www.metabo.com for addresses.
You can download a list of spare parts from

www.metabo.com.

Do not allow battery packs to come into contact with

water!

Protect the environment, and do not dispose

of power tools and battery packs with house-

hold waste. Observe national regulations on

separated collection and recycling of disused

machines, packaging and accessories.
Discharge the battery pack in the power tool before

disposal. Prevent the contacts from short-circuiting

(e.g. by protecting them with adhesive tape).

Fig. L.

We reserve the right to make technical

improvements.

U

= Voltage of battery pack

n

0

 = No-load

speed

Tightening torque for screwing:

M

1

= Soft screwing application (wood)

M

3

= Hard screwing applications (metal)

M

4

= Adjustable torque

8. Troubleshooting

9. Accessories

10. Repairs

11. Environmental Protection

12. Technical Data
