ENGLISH

en

12

Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

Transport of li-ion battery packs:

The shipping of li-ion battery pack is subject to laws

related to the carriage of hazardous goods (UN

3480 and UN 3481). Inform yourself of the currently

valid specifications when shipping li-ion battery

packs. If necessary, consult your freight forwarder.

Certified packaging is available from Metabo.
Only send the battery pack if the housing is intact

and no fluid is leaking. Remove the battery pack

from the machine for sending. Prevent the contacts

from short-circuiting (e.g. by protecting them with

adhesive tape).

Illustrations are provided at the beginning of the

operating instructions.

Symbol explanation:

Movement direction
Slow
Fast
First gear
Second gear
Screws
Drill bit
Without torque limitation
Impact drilling
Torque

Fig. A

1 Keyless chuck

2 Additional handle

3 Slide switch (normal drilling, impact drilling) *

4 Slide switch (1st/2nd gear)

5 Button (switch between 'max. torque' and function

set at setting wheel (13)) *

6 Rotation selector switch (rotation setting,

transport lock) - both sides of the machine

7 Bit depot *

8 Belt hook *

9 Battery pack release button

10 Capacity indicator button

11 Capacity and signal indicator

12 Battery pack

13 Setting wheel (pulse function, torque control,

where applicable 'max. torque') *

14 LED lights

15 Trigger switch

*equipment-specific

7.1 Battery pack, capacity and signal display

Fig. B

Charge the battery pack before use.
If performance diminishes, recharge the battery

pack.
The ideal storage temperature is between 10 °C

and 30 °C.

7.2 Removing, replacing battery pack

Fig. C

7.3 Setting direction of rotation, transporting

safety device (switch-on lock)

Fig. D

7.4 Selecting gear stage

Fig. E

Only actuate slide switch (4) with the motor at

a standstill!

7.5 Setting for normal drilling,

impact drilling

Fig. A

Press the slide switch (3).

7.6 Setting torque control, maximum torque,

pulse function

Do not work for long periods with pulse func-

tion switched on! (The motor can overheat.)

Machines with designation ...18 LTX

BL Quick

...:

Fig. F

Turn the setting wheel (13) to switch on the

pulse

function

 (button (5) flashes) or to switch on the

torque control

 (button (5) lights up continuously)

For

maximum torque

 (drilling position), press the

button (5) (the button (5) is not illuminated). To acti-

vate the settings of setting wheel again: press the

button (5) again or turn the setting wheel.
Machines with designation ...18 LTX

Impuls/

Quick,

...18 LTX

BL Impuls

:

Fig. G

Set the desired operating mode at the setting wheel

(13):
1...10 =  torque

control

Drill bit =  maximum torque

Impuls = pulse

function

7.7 Switching on/off, setting speed

Fig. A

Switching on, speed:

 Press the trigger (15). The

speed can be changed by pressing in the

trigger.

Switching off:

release the trigger switch (15). Note:

The noise that the machine makes when it

switches off is due to the design (quick stop)

5. Figures

6. Overview

Nm

7. Use
