ENGLISH

en

12

Impact drilling
Torque

Fig. A

1 Keyless  chuck

2 Additional handle

3 Slide switch (normal drilling, impact drilling) *

4 Slide switch (1st/2nd gear)

5 Button (switch between 'max. torque' and function

set at setting wheel (13)) *

6 Rotation selector switch (rotation setting,

transport lock) - both sides of the machine

7 Bit  depot  *

8 Belt  hook  *

9 Battery pack release button

10 Capacity indicator button

11 Capacity and signal indicator

12 Battery pack

13 Setting wheel (pulse function, torque control,

where applicable 'max. torque') *

14 LED lights

15 Trigger switch

*equipment-specific

7.1 Battery pack, capacity and signal display

Fig. B

Charge the battery pack before use.
If performance diminishes, recharge the battery

pack.
The ideal storage temperature is between 10 °C

and 30 °C.

7.2 Removing, replacing battery pack

Fig. C

7.3 Setting direction of rotation, transporting

safety device (switch-on lock)

Fig. D

7.4 Selecting gear stage

Fig. E

Only actuate slide switch (4) with the motor at

a standstill!

7.5 Setting for normal drilling,

impact drilling

Fig. A

Press the slide switch (3).

7.6 Setting torque control, maximum torque,

pulse function

Do not work for long periods with pulse func-

tion switched on! (The motor can overheat.)

Machines with designation ...18 LTX

BL Quick

...:

Fig. F

Turn the setting wheel (13) to switch on the

pulse

function

 (button (5) flashes) or to switch on the

torque control

 (button (5) lights up continuously)

For

maximum torque

 (drilling position), press the

button (5) (the button (5) is not illuminated). To acti-

vate the settings of setting wheel again: press the

button (5) again or turn the setting wheel.
Machines with designation ...18 LTX

Impuls/

Quick,

...18 LTX

BL Impuls

:

Fig. G

Set the desired operating mode at the setting wheel

(13):
1...10 =  torque

control

Drill bit =  maximum torque

Impuls = pulse

function

7.7 Switching on/off, setting speed

Fig. A

Switching on, speed:

 Press the trigger (15). The

speed can be changed by pressing in the

trigger.

Switching off:

release the trigger switch (15). Note:

The noise that the machine makes when it

switches off is due to the design (quick stop)

and has no influence on the function or the

service life of the machine.

7.8 Keyless chuck

Fig. H

With a soft tool shank, retightening may be required

after a short period of operation.

Notes on machines with the designation SB...:

1. The ratchet sound which can possibly be heard

after opening the drill chuck is functional and is

switched off by a reverse rotation of the sleeve.

2. Clamping tool:

Turn sleeve (1) in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The chuck is not yet fully tight-

ened!

 Keep turning the sleeve (

it must "click"

when turning)

) until it cannot be turned any

further -

only now

 is the tool

 safely

 clamped.

Cleaning:

 From time to time, hold the machine

vertically with the keyless chuck facing

downwards and turn the sleeve fully in direction

"GRIP, ZU" and then turn fully in direction

"AUF, RELEASE". The dust collected falls from

the keyless chuck.

7.9 Unscrewing chuck

Fig. I

Employ the same procedure when attaching the

chuck, except in reverse order.

7.10 Chuck with quick bit change system (for

BS 14.4 LTX Quick, BS 18 LTX Quick)

Fig. J

To remove:

Push the interlock ring forward (a),

advance and pull off the chuck (b).

To mount:

Push the interlock ring forward and

move the chuck as far as the limit stop on the drill

spindle.

6. Overview

7. Use

Nm
