ENGLISH
en
11
7.9 On/Off switch, setting the speed
Switching on, speed:
rotational speed can be changed at the trigger
switch by pressing.
Switching off:
Release the trigger (13). Note: The
noise that the machine makes when it switches
off is due to the design (quick stop) and has no
influence on the function or the service life of
the machine.
7.10 LED lights
For working on dimly lit areas. The LED lights (12)
light up when the machine is switched on.
7.11 Opening, tensioning the keyless chuck
Opening the chuck
Turn sleeve (2) in the direction "AUF, RELEASE".
The grating sound which may be heard after
opening the drill chuck is functional and is stopped
by turning the sleeve (2) in the opposite direction.
Clamping the tool
- Open the keyless chuck and insert the tool as far
as possible.
- Turn sleeve (2) in direction "GRIP, ZU" until the
noticeable mechanical resistance has been
overcome.
-
Caution! The tool is not yet clamped!
Keep
turning the sleeve (
it must "click" when turning
)
until it cannot be turned any further -
only now
is
the tool
securely
clamped.
7.12 Chuck with Quick replacement
system
(for BS 18 LTX Quick)
To remove:
Push the interlock ring forward (a),
advance and pull off the chuck (b).
To mount:
Push the interlock ring forward and move the
chuck as far as the limit stop on the drill spindle.
7.13 Unscrewing the chuck
(for BS 14.4 LTX Impuls, BS 18 LTX,
BS 18 LTX Impuls, SB 14.4 LTX Impuls, SB
18 LTX, SB 18 LTX Impuls)
- Open the keyless chuck.
- Slacken the screw (a) (note: left-handed thread!).
- Lock the spindle using a spanner (c) and unscrew
the keyless chuck (2) using spanner (b).
Employ the same procedure when attaching the
chuck, except in reverse order.
From time to time, hold the machine vertically with
the chuck facing downwards and turn the sleeve
fully in the direction "GRIP, ZU" and then turn fully in
the direction "AUF, RELEASE". The dust collected
falls from the keyless chuck.
Drilling
- Preferably in 2nd gear (high speed).
- Activate the pulse function (depending on the
model) to drill steel, aluminium or tiles without
centre punching or pre-drilling.
- Drill tiles and other brittle materials without impact
(depending on the model).
- In the case of deep bores, pull the drill bit out of the
bore from time to time in order to remove the drill
dust or swarf.
Screws
- Preferably in 1st gear (low speed) and with torque
control.
- Before inserting screws with deformed heads into
wood, activate the pulse function (depending on
the model).
- Activate the pulse function (depending on the
model) to reach the maximum torque while
inserting screws.
- The drill chuck can be removed for screwdriving.
Insert the bit directly in the hexagon socket on the
spindle.
With the BS 18 LTX Quick, the screwdriver bit is
held in place by a magnet. Use the clamping bush
for other tools. (The screwdriver bit is retained if a
bit clamping bush (accessory, order no. 6.31281)
is fitted.)
Thread tapping
- Lubricate the dies.
- Select 1st gear (low speed).
- Adjust torque control.
Use only genuine Metabo accessories.
See page 4.
AUF, RELEASE
2
GRIP, ZU
b
a
8. Maintenance, cleaning
9. Tips and Tricks
10. Accessories
2
c
