ENGLISH

en

10

Open the clamping ring by turning the additional

handle (1) anticlockwise. Push the additional

handle onto the collar of the machine. Securely

tighten the additional handle at the angle required

for the application.

7.1

The machine's multifunctional monitoring

system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. A warning signal sounds

(continuous beeping). The beeping stops after a

maximum of 30 seconds or when the trigger is

released (13).

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost flat

 (the electronics

prevent the battery pack from discharging totally

and avoid irreparable damage).

If one LED is flashing (9), the battery pack is

almost flat. If necessary, press the  (8) button

and check the LEDs  (9) to see the charge level.

If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

Leave the machine or battery pack to cool.
Note: If the battery pack feels very warm, the

pack will cool more quickly in your "AIR

COOLED" charger.
Note: The machine will cool more quickly if you

operate it at idling speed.

3. If the

current is too high

(for example, if the

machine seizes continuously for long periods),

the machine switches off.

Switch off the machine at the trigger (13). Then

continue working as normal. Try to prevent the

machine from seizing.

7.2 Battery pack

Charge the battery pack before use (10).
If performance diminishes, recharge the battery

pack.

"Li-Power"

li-ion battery packs

have a capacity

and signal indicator: (9)

- Press the  (8) button, the LEDs indicate the charge

level.

- If one LED is flashing, the battery pack is almost

flat and must be recharged.

7.3 Removing and inserting the battery pack
Removal:

Press the battery pack release  (7) button and pull

the battery pack (10) forwards.

Inserting:

Slide in the battery pack (10) until it engages.

7.4 Setting the direction of rotation,

engaging the transporting safety device

(switch-on lock)

Set the rotation selector switch (6).
See page 2.

R

= Clockwise setting

L

= Counter-clockwise setting

0

= Central position: transport lock setting

(switch-on lock)

7.5 Selecting gear stage

Do not actuate the switch (5) unless the motor

has stopped completely!

If the switch (5) cannot be turned up to the stop,

however, press the trigger (13) slightly so that the

motor rotates slowly. It will then be possible to turn

the switch (5) all the way up to the stop.
Press the switch (5) (left or right of the machine).

1st gear setting (low speed),

very high torque
2nd gear setting (high speed)

7.6 Setting the torque limit

Press the slide switch (4).

1...

=  Torque setting (for working with torque

control)

Note:  the torque can be adjusted to different

settings depending on the gear selected! In

2nd gear from 1.5 to 3.5 Nm and in 1st gear

from 3.5 to 12.5 Nm.

Note:  Once the set torque has been reached, the

screwdriver clutch emits a rattling noise

and the machine is automatically switched

off.

=  Drill setting - no torque control

(for max. torque)

7.7 Drilling and impact drilling

(depending on the model)

Press the slide switch (3).

= Impact drilling

Note: Always work at high speeds when

impact drilling.

=  Normal drilling without impact

7.8 Activating the pulse function

(depending on the model)

Do not work for long periods with pulse

function switched on! (The motor can

overheat.)
Press the button  (11)

 to activate or deactivate

the pulse function.
The button  (11) flashes when the pulse function is

active.
Note: If the machine is not used for approx. 5

minutes, the pulse function switches off

automatically and the flashing button  (11) goes out.

7. Use
