Use suitable accessories for special work. In this

way, fewer particles enter the environment in an

uncontrolled manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

Transport of li-ion battery packs:

The shipping of li-ion battery pack is subject to laws

related to the carriage of hazardous goods (UN

3480 and UN 3481). Inform yourself of the currently

valid specifications when shipping li-ion battery

packs. If necessary, consult your freight forwarder.

Certified packaging is available from Metabo.
Only send the battery pack if the housing is intact

and no fluid is leaking. Remove the battery pack

from the machine for sending. Prevent the contacts

from short-circuiting (e.g. by protecting them with

adhesive tape).

Illustrations are provided at the beginning of the

operating instructions.

Symbol explanation:

Movement direction
Slow
Fast
First gear
Second gear
Screws
Drill bit
Without torque limitation
Impact drilling
Torque

Fig. A

1 Keyless chuck

2 Sleeve (torque, drilling, impact drilling)*

3 Switch (1st/2nd gear)

4 Rotation selector switch (rotation setting,

transport lock) - both sides of the machine

5 Bit depot *

6 Belt hook *

7 Battery pack release button

8 Capacity indicator button

9 Capacity and signal indicator

10 Battery pack

11 LED lights

12 Trigger switch

*equipment-specific

7.1 Battery pack, capacity and signal display

Fig. B

Charge the battery pack before use.
If performance diminishes, recharge the battery

pack.
The ideal storage temperature is between 10°C and

30°C.

7.2 Removing, replacing battery pack

Fig. C

7.3 Setting direction of rotation, transporting

safety device (switch-on lock)

Fig. D

7.4 Selecting gear stage

Fig. E

Do not set the switch (3) unless the motor has

stopped completely!

7.5 Setting torque limitation,

drilling, impact drilling

Fig. F

7.6 Switching on/off, setting speed

Fig. A

Switching on, speed:

 press the trigger (12). The

speed can be changed by pressing in the

trigger.

Switching off:

 release the trigger (12). Note: The

noise that the machine makes when it switches

off is due to the design (quick stop) and has no

influence on the function or the service life of

the machine.

7.7 Keyless chuck

Fig. G

With a soft tool shank, retightening may be required

after a short period of operation.

Notes on machines with the designation SB...:

1. The ratchet sound which can possibly be heard

after opening the drill chuck is functional and is

switched off by a reverse rotation of the sleeve.

2. Clamping tool:

Turn sleeve in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The chuck is not yet fully tight-

ened!

 Keep turning the sleeve (

it must "click"

when turning)

) until it cannot be turned any

further -

only now

 is the tool

 safely

 clamped.

Cleaning:

 From time to time, hold the machine

vertically with the keyless chuck facing

downwards and turn the sleeve fully in direction

"GRIP, ZU" and then turn fully in direction

5. Figures

6. Overview

Nm

7. Use
