ENGLISH

en

10

Torque

Fig. A

1 Keyless  chuck

2 Sleeve (torque, drilling, impact drilling)*

3 Switch (1st/2nd gear)

4 Rotation selector switch (rotation setting,

transport lock) - both sides of the machine

5 Battery pack release button

6 Capacity indicator button

7 Capacity and signal indicator

8 Battery pack

9 LED lights

10 Ttrigger

*equipment-specific

7.1 Battery pack, capacity and signal display

Fig. B

Charge the battery pack before use.
If performance diminishes, recharge the battery

pack.
The ideal storage temperature is between 10 °C

and 30 °C.

7.2 Removing, replacing battery pack

Fig. C

7.3 Setting direction of rotation, transporting

safety device (switch-on lock)

Fig. D

7.4 Selecting gear stage

Fig. E

Do not set the switch (3) unless the motor has

stopped completely!

7.5 Setting torque limitation,

drilling, impact drilling

Fig. F

7.6 Switching on/off, setting speed

Fig. A

Switching on, speed:

 press the trigger (10). The

speed can be changed by pressing in the

trigger.

Switching off:

 release the trigger (10). Note: The

noise that the machine makes when it switches

off is due to the design (quick stop) and has no

influence on the function or the service life of

the machine.

7.7 Keyless chuck

Fig. G

With a soft tool shank, retightening may be required

after a short period of operation.

Notes on machines with the designation SB...:

1. The ratchet sound which can possibly be heard

after opening the drill chuck is functional and is

switched off by a reverse rotation of the sleeve.

2. Clamping tool:

Turn sleeve (1) in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The chuck is not yet fully tight-

ened!

 Keep turning the sleeve (

it must "click"

when turning)

) until it cannot be turned any

further -

only now

 is the tool

 safely

 clamped.

Cleaning:

 From time to time, hold the machine

vertically with the keyless chuck facing

downwards and turn the sleeve fully in direction

"GRIP, ZU" and then turn fully in direction

"AUF, RELEASE". The dust collected falls from

the keyless chuck.

7.8 Unscrewing chuck

Fig. H

Employ the same procedure when attaching the

chuck, except in reverse order.

8.1 The machine's multifunctional monitoring

system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. A warning signal sounds (contin-

uous beeping). The beeping stops after a maximum

of 30 seconds or when the trigger  (10) is released.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost empty

Fig. A, B

(The

electronics protect the battery pack against

damage through total discharge).

If one LED is flashing (7), the battery pack is

almost flat. If necessary, press the  (6) button

and check the LEDs  (7) to see the charge level.

If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

Leave the machine or battery pack to cool.
Note: If the battery pack feels very warm, the

pack will cool more quickly in an "AIR COOLED"

charger.
Note: The machine will cool more quickly if you

operate it at idling speed.

3. If the

current is too high

(for example, if the

machine seizes continuously for long periods),

the machine switches off.

Switch off the machine at the trigger (10). Then

continue working as normal. Try to prevent the

machine from seizing.

Use only genuine Metabo accessories.
For a complete range of accessories, see

www.metabo.com or the main catalogue.

6. Overview

7. Use

Nm

8. Troubleshooting

9. Accessories
