ENGLISH

en

10

Reduce dust exposure with the following measures:

- Do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits.

- Use an extraction unit and/or air purifiers.

- Ensure good ventilation of the workplace and

keep it clean using a vacuum cleaner. Sweeping

or blowing stirs up dust.

Vacuum or wash protective clothing. Do not blow,

beat or brush.

See page 2.

1 Additional handle

2 Thread for screwing in the additional handle

3 Handle

4 Locking button (only for use in drill stand)

5 Trigger

6 Thumb-wheel for gear selection

7 Slot on machine neck

8 Removal tool

9 Drill spindle

10 Toolholder

Before plugging in, check to see that the rated

mains voltage and mains frequency, as

specified on the rating label, match your power

supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.

The extension cable must be suitable for the

machine power rating (see Technical

Specifications). If using a roll of cable, always roll up

the cable completely.

6.1 Assembly of the additional handle

When the drill bit jams, very high torques may

be present. Therefore for safety reasons,

always use the additional handle  (1) supplied.

In the event of jamming, it is not sufficient to hold the

machine only at the handle (3). There is a risk of

injury to the user.
Screw the additional handle (1) into the thread (2)

and pull firmly by hand.

7.1 Switching On and Off

Avoid load on the machine until it come to a

standstill.

Torque activation

To switch on: press the trigger switch (5).
230 V: The rotational speed can be changed at the

trigger switch by pressing.
Switching off: Release the trigger (5).

Continuous activation

(ONLY for use in drill stand):

To switch on: press the trigger switch (5) and lock

with locking button (4).
To switch off: press and release the trigger switch

(5).

Use the locking button (4)  only when the

machine is in the drill stand.
The locking button (4) must be released after

every machine-related standstill or after a

current interruption to prevent accidental restart of

the machine (risk of injury) !

7.2 Three-speed gearing

Do not actuate the thumb-wheel (6) unless the

motor has completely stopped.

Select the desired speed by turning the thumb-

wheel (6).
If necessary, the switching procedure can be

supported by turning the drill spindle slightly.

7.3 Overload protection

The machine is equipped with a mechanical

overload protection device to protect the operator,

motor and tool.
If the tool jams suddenly, the drill spindle is

decoupled from the motor by means of a slip clutch.

The slip clutch is designed to absorb impact and

excessive load. As it is only an aid, and does not

provide total protection, you should always drill

carefully. To retain its operability, it should slip

through for a maximum of 2 seconds. In case of

excessive wear, it must be replaced by an

authorised specialist workshop.

7.4 Inserting and removing tool

Inserting tool:

Perfect seating of the tool in the drill spindle (9)

can only be guaranteed if the female taper of

the drill spindle and the taper shank of the tool are

free of dirt and grease.

Caution ! Never use excessive force to press

tools into the female taper of the drill spindle!
Always use sharp tools in perfect condition.
Switch off the machine. Pull the mains plug out

of the socket.

Tools with taper shank MK3 can be inserted directly

in the toolholder (10).
For all other tools, refer to the chapter 10.

Accessories and the illustration of page 4.

Removing tool:

Insert the removal tool - with the sloping edge

against the drill - in the slot  (7) on the machine neck.

If it cannot be inserted through the drill spindle, you

should turn it slightly by hand. Drive out the tool by

knocking lightly on the removal tool with a hammer.

Regularly clean the power tool’s air vents.

5. Overview

6. Commissioning

7. Use

8. Cleaning
