7
The impact force can be changed in four steps: hard,
medium, soft, and T mode.
This allows a tightening suitable to the work.
Every time the button
is pressed, the number of blows
changes in four steps.
"T" is a special mode for fastening self drilling screws. In
this mode, the tool starts to drive a screw with faster
rotation, which is suited for drilling with the self-drilling
-screw tip. Once the tool starts to tighten the screw, it
impacts in medium force grade.
For approximately one minute after releasing the switch
trigger, the impact force can be changed.
NOTE:
•
When all lamps on the switch panel go out, the tool
is turned off to save the battery power. The impact
force grade can be checked by pulling the switch
trigger to the extent that the tool does not operate.
•
While pulling the switch trigger, the impact force
grade cannot be changed.
Indicating the remaining battery
capacity
Fig.7
When you pull the switch trigger, the LED display shows
the remaining battery capacity.
The remaining battery capacity is shown as the following
table.
LED indicator status
Remaining battery capacity
About 50% or more
About 20% - 50%
About less than 20%
012273
NOTE:
•
When the LED display goes off, the tool is turned off
to save the battery power. To check the remaining
battery capacity, slightly pull the switch trigger.
•
The LED display goes off approximately one
minute after releasing the switch trigger.
•
When the tool is overheated, the light flashes once
per second for one minute, and then the LED
display goes off. In this case, cool down the tool
before operating again.
•
When the LED display lights up and the tool stops
even with a recharged battery cartridge, cool down
the tool fully. If the status will not change, stop using
and have the tool repaired by a Makita local service
center.
ASSEMBLY
CAUTION:
•
Always be sure that the tool is switched off and the
battery cartridge is removed before carrying out
any work on the tool.
Installing or removing driver bit or socket bit
Fig.8
Use only bits that has inserting portion shown in the
figure.
For tool with shallow bit hole
A=12mm
B=9mm
Use only these type of bit. Follow the
procedure (1).
(Note) Bit-piece is not necessary.
006348
For tool with deep bit hole
To install these types of bits, follow
the procedure (1).
To install these types of bits, follow
the procedure (2).
(Note) Bit-piece is necessary for
installing the bit.
A=17mm
B=14mm
A=12mm
B=9mm
011405
Procedure 1
For tool with normal sleeve
Fig.9
To install the bit, pull the sleeve in the direction of the
arrow and insert the bit into the sleeve as far as it will go.
Then release the sleeve to secure the bit.
For tool with one-touch type sleeve
To install the bit, insert the bit into the sleeve as far as it
will go.
Procedure 2
In addition to the procedure(1) above, insert the bit-piece
into the sleeve with its pointed end facing in.
Fig.10
To remove the bit, pull the sleeve in the direction of the
arrow and pull the bit out.
NOTE:
•
If the bit is not inserted deep enough into the sleeve,
the sleeve will not return to its original position and
the bit will not be secured. In this case, try
