REPLACING THE CARBON BRUSHES

Worn (shorter than 5 mm), burnt or cracked motor carbon brushes should be immediately replaced.

Both carbon brushes should be always replaced at the same time.

Ɣ

Loosen the covers of the carbon brushes (

4

) (

fig. E

).

Ɣ

Remove the worn carbon brushes.

Ɣ

Remove any carbon dust using compressed air of a lower pressure.

Ɣ

Insert new carbon brushes (brushes should easily slide into the brush holders) (

fig. F

)

Ɣ

Fasten the covers of the carbon brushes (

4

).

After the carbon brushes are replaced, switch on the tool with any load for approximately 3 minutes
to make the carbon brushes fit the motor commutator. Carbon brushes should be replaced by a
qualified person using original spare parts only.

All types of faults and defects should be eliminated by an authorised service of the manufacturer.

SPECIFICATIONS

RATED DATA

Electric drill driver

Parameter

Value

Power supply voltage

230 V AC

Power supply frequency

50 Hz

Rated power

250 W

Idle speed range:

speed I

0-400 min

-1

speed II

0-1450 min

-1

Chuck range

0.8-10 mm

Torque control range

1-23 plus drilling

Maximum torque

21.5 Nm

Protection class

II

Weight

1.3 kg

Year of manufacturer

2016

NOISE AND VIBRATION DATA

Acoustic pressure level: Lp

A

 = 85 dB(A) K = 3 dB(A)

Acoustic power level: Lw

A

 = 96 dB(A) K = 3 dB(A)

Vibration acceleration value: a

h

 = 3.25 m/s

2

 K = 1,5 m/s

2

ENVIRONMENTAL PROTECTION

Do not dispose of electrically powered products with household wastes, they should be utilized in
proper plants. Obtain information on wastes utilization from your seller or local authorities. Used up
electric and electronic equipment contains substances active in natural environment. Unrecycled
equipment constitutes a potential risk for environment and human health.

* Right to introduce changes is reserved.
