TRANSLATION OF THE ORIGINAL INSTRUCTIONS
IMPACT DRILL
58G712
CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL CAREFULLY AND KEEP IT FOR FUTURE
REFERENCE.
DETAILED SAFETY REGULATIONS
Ɣ
Use ear protectors when operating impact drill.
Noise hazards may cause hearing loss.
Ɣ
Use additional handles supplied with the tool.
Loss of control may cause operator personal injury.
Description of improper use
Do not throw the tool, do not overload, do not immerse in water or other fluids, do not use for mixing
adhesive or cement mortars, do not hang, carry, pull or unplug the power tool by pulling the cord. Avoid
using long extension cords.
Accessories that you can use
Wood, metal and masonry drills, grinding discs and wire brushes (wear safety goggles when using grinding
discs and wire brushes).
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and additional safety systems are used,
nevertheless there is always a small risk of operational injuries.
CONSTRUCTION AND USE
Impact drills are hand operated power tools with insulation class II. Tools are driven by single-phase
commutator motors with rotational speed reduced with gear transmission. This type of power tools is
widely used for making holes in wood, wood-like materials, metals, ceramics and plastics (rotation only),
and concrete, bricks and alike (with impact). Range of use covers repair and building works, woodworking
and any work from the scope of individual, amateur activities (tinkering).
Use the power tool according to the manufacturer’s instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1.
Drill chuck
2.
Operation mode switch
3.
Switch lock button
4.
Direction selector switch
5.
Speed control wheel
6.
Switch
7.
Additional handle
8.
Depth gauge rod
9.
Gear switch
* Slight differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
