Batteries heat up very strongly during charging process. Do not work just after charging has been
finished, wait until the battery cools down to room temperature. It will prevent battery damage.
BATTERY LEVEL INDICATION
Each pressing the switch button turns on battery level indication.
Drill features battery level indication (4 LED diodes) (
9
). To check battery level status, press the switch
button (
8
) (
fig. C
). When all diodes are lit, the battery level is high. When 2 diodes are on, the battery is
partially discharged. When only one diode is lit, the battery is discharged and must be recharged.
SPINDLE BRAKE
Drill is equipped with electronic brake that stops the spindle immediately after the switch button (
8
) is
released. The brake ensures precision when screwing or drilling and prevents free spindle rotation after
switching off.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
Switching on
– press the switch button (
8
).
Switching off
– release the switch button (
8
).
Each time the switch button (
8
) is pressed, the LED diode (
10
) lights up to illuminate the workplace.
ROTATIONAL SPEED CONTROL
Increase or reduce pressure on the switch button (
8
) to adjust drilling or driving speed while operating.
Speed adjustment allows for a soft start, which prevents dill slipping when drilling holes in gypsum or
glaze, and allows for operation control when screwing in and out.
OVERLOAD CLUTCH
Set the torque adjustment ring (
3
) in appropriate position to permanently set overload clutch to defined torque
value. When the set torque is reached, overload clutch disconnects automatically. It prevents screwing screws
too deep or damaging the drill.
TORQUE ADJUSTMENT
Ɣ
Different screws and materials require different torque to be applied.
Ɣ
The bigger the number corresponding to given position, the bigger is the torque (
fig. D
).
Ɣ
Set the torque adjustment ring (
3
) to appropriate torque value.
Ɣ
Always start operation with low torque.
Ɣ
Increase the torque gradually until obtaining desired results.
Ɣ
Use higher settings to unscrew screws.
Ɣ
When drilling, choose setting marked with the drill symbol. The torque is the greatest with this setting.
Ɣ
Knowledge how to choose appropriate torque setting comes with practice.
Setting the torque adjustment ring in the drilling position deactivates the overload clutch.
WORKING TOOL INSTALLATION
Ɣ
Set the direction selector switch (
5
) in the middle position.
Ɣ
By turning the ring of the quick release chuck (
2
) counter clockwise (see mark on the ring) you can spread
jaws enough to insert drill or driver bit (
fig. E
).
Ɣ
To install working tool, turn the ring of the quick release chuck (
2
) clockwise and tighten.
Deinstallation of the tool is similar to installation, only the sequence of actions is reversed.
Make sure the tool position is correct when installing drill or driver bit in the quick release chuck. Use
additional magnetic adapter as an extension when using short driver bits.
