6

EN

ASSEMBLY

 Before assembly, always switch off the
machine and remove the mains plug from
the mains.

Exchanging and removing drill bits
Fig. A - B

The machine is suitable for use of the following
drill bits:
•   Wood  (HSS)
•   Metal  (HSS)
•   Concrete / masonry (hard metal)

 Before exchanging bits, first remove the
power plug from the wall socket.

 Inspect bits regularly during use. Blunt
bits should be re-sharpened or replaced.

•   Open the chuck (6) by turning the front


sleeve (11) clockwise while simultaneously

holding the rear sleeve (10) or turning it

counterclockwise and insert the bit into the

chuck opening.

•   Tighten the bit by turning the front sleeve (11)


counterclockwise while simultaneously
holding the rear sleeve (10) or turning it
clockwise.

Mounting and removing the auxiliary grip (fig. C)

Mounting

•   Loosen the auxiliary grip (8).
•   Slide the auxiliary grip (8) over the chuck (6).
•   Turn the auxiliary grip (8) to the required

position.

•   Tighten the auxiliary grip (8).

Removing

•   Loosen the auxiliary grip (8).
•   Remove the auxiliary grip (8) from the chuck (6).
•   Tighten the auxiliary grip (8).

Mounting and removing the depth stop (fig. D)

The depth stop is used to set the maximum
drilling depth.

USE

Switching on and off (fig. A)

•   To switch on the machine, press the on/off

switch (1). The further the on/off switch (1) is
pressed, the higher the speed of the machine.

•   To switch the machine to continuous mode,

keep the on/off switch (1) pressed and
simultaneously press the lock-on button (2).

•   To switch off continuous mode, press the on/

off switch (1) again.

Forward/reverse switch (fig. A)

Do not change the direction of rotation
during use.

•   For clockwise rotation, slide the forward/

reverse switch (4) to the left.

•   For counterclockwise rotation, slide the

forward/reverse switch (4) to the right.

Setting the maximum drilling speed (fig. A)

Do not set the speed during use.

•   Turn the speed adjustment wheel (3) clockwise

to increase the maximum drilling speed.

•   Turn the speed adjustment wheel (3)

counterclockwise to decrease the maximum
drilling speed.

Setting the operating mode (fig. E)

Do not change the operating mode
during use.

•   Set the switch (5) to position ”A” for drilling.
•   Set the switch (5) to position ”B” for hammer

drilling.

CLEANING AND MAINTENANCE

 Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.

•   Regularly clean the housing with a soft cloth.
•   Keep the ventilation slots free from dust and

dirt. If necessary, use a soft, moist cloth to
remove dust and dirt from the ventilation slots.
