5

EN

•   Make sure that the maximum speed for the

accessory is larger than or the same as the
maximum speed of the machine. Refer to the
rating plate on the machine.

•   Before use, remove all nails and other metal

objects from the workpiece.

•   Make sure that the workpiece is properly

supported or fixed.

•   Keep your hands away from the workpiece

during use.

•   Never put the machine down on a table or a

workbench before it has been switched off.

Electrical safety

 Always check that the voltage of the
power supply corresponds to the voltage
on the rating plate.

•   Do not use the machine if the mains cable or

the mains plug is damaged.

•   Only use extension cables that are suitable

for the power rating of the machine with a
minimum thickness of 1.5 mm

2

. If you use a

extension cable reel, always fully unroll the
cable.

Technical specifications

Mains voltage

 230  V~

Mains frequency

 50  Hz

Power input

800 W

No-load speed

 0 - 3.000 /min

Impact rate

 0 - 48.000 /min

Protection class

IP 20

Weight

2.2 kg

Max. drill diameter

Wood

 25  mm

Concrete

 13  mm

Steel

 10  mm

Noise values

Sound pressure (L

PA

)

 91.7  dB(A)

Acoustic power (L

WA

)

 102.7  dB(A)

Uncertainty (K)

3 dB(A)

Vibration values

Impact drilling mode

15.238 m/s

2

Drilling into metal, a

h,D

 4.98  m/s

2

Uncertainty (K)

 1.5  m/s

2


Wear hearing protection.

Vibration level

The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.

-   using the tool for different applications, or with

different or poorly maintainted accessories,
may significantly increase the exposure level

-   the times when the tool is switched off or when

it is running but not actually doing the job, may
significantly reduce the exposure level

Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.

DESCRIPTION (FIG. A)

Your impact drill has been designed for drilling
holes in wood, metal and plastics and for hammer
drilling in brick and concrete.


 1.   On/off  switch

 2.   Lock-on  button

  3.   Speed adjustment wheel


 4.   Forward/reverse  switch

   5.   Switch for drilling / hammer drilling


 6.   Chuck

 7.   Main  grip

 8.   Auxiliary  grip

 9.   Depth  stop

 10.  Rear  sleeve

 11. Front  sleeve

  12. Power indicator light
