5

EN

 Before exchanging bits, first remove the
power plug from the wall socket.

Inspect bits regularly during use. Blunt
bits should be re-sharpened or replaced.

•   Open the chuck (1) by turning the front

sleeve (10) clockwise while simultaneously
holding the rear sleeve (9) or turning it
counterclockwise and insert the bit into the
chuck opening.

•   Tighten the bit by turning the front sleeve

(10) counterclockwise while simultaneously
holding the rear sleeve (9) or turning it
clockwise.

Setting depth stop
Fig. A

•   Loosen the side handle (8) by turning it

counterclockwise.

•   Insert the depth stop (3) through the hole in the

side handle ring.

•  Slide the ruler to the desired depth.
•   Retighten the screw firmly by turning it clockwise.

The On/Off switch
Fig. A

•   Switch the machine on by pressing the On/Off

switch (5). When you release the On/Off switch
(5) the machine will turn off.

•   The rotation-speed can be adjusted by

pressing the On/Off switch (5) harder for
raising the rotation-speed or release pressure
for lowering the rotation-speed.

Lock-on Button
Fig. A

•   You can lock the On/Off switch (5) by pressing

the On/Off switch (5) and then pressing the
lock-on button (4).

•   To release the switch-lock; shortly press the

On/Off switch (5) again.

Adjusting of the maximum rotation speed
Fig. A

•   Adjust the speed by turning the speed

adjustment wheel (6) to the desired maximum
rotation speed.

Switching the direction of rotation
Fig. A

 Do not change the direction of rotation
during use.

•   Direction of rotation counter-clockwise: shift

left/right rotation switch (7) to “

”.

•   Direction of rotation clockwise: shift left/right

rotation switch (7) to “

”.

Function selection switch
Fig. A

 In order to avoid damage to the machine,
adjusting the function selection switch (2)
shall only be done when machine is not
running

•   Set the function selection switch (2) to “

”

for drilling.

•   Set the function selection switch (2) to “   ”

for hammer drilling.

User tips

Always use the machine with the side handle
firmly anchored in place - you will not only work
with more comfort, you will also work with more
precision.

Caution: drilling bits and hammer drilling
bits can get very hot

Drilling and hammer drilling

•   For large holes, for instance in very hard

concrete, start using a smaller bit for pilot
drilling first , then drill to nominal size.

•   Hold the machine firmly with 2 hands. Be

aware the drill can jam and because of that
machine might suddenly turn (Especially when
drilling deep holes).

•   Do not apply a lot of pressure on the machine,

let the machine do the work.

4. MAINTENANCE

 Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.
