4
EN
Max. drill diameter
Wood
25 mm
Steel
10 mm
Weight
1.50 kg
Noise values
Sound pressure (L
PA
)
91.80 + 3 dB(A)
Acoustic power (L
WA
)
102.80 + 3 dB(A)
Vibration values
Drilling into metal, a
h,D
6.129 + 1.5 m/s
2
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
- using the tool for different applications, or with
different or poorly maintained accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
Description
The numbers in the text refer to the diagrams on
page 2.
Fig. A
1. Chuck
4. Lock-on button
5. On/Off switch
7. Left/right rotation switch
Fig. B
11. Rear sleeve
12. Front sleeve
3. OPERATING
Exchanging and removing drill bits
Fig. A - B
Before exchanging bits, first remove the
power plug from the wall socket.
Inspect bits regularly during use. Blunt
bits should be re-sharpened or replaced.
• Open the chuck (1) by turning the front
sleeve (12) clockwise while simultaneously
holding the rear sleeve (11) or turning it
counterclockwise and insert the bit into the
chuck opening.
• Tighten the bit by turning the front sleeve (12)
counterclockwise while simultaneously holding
the rear sleeve (11) or turning it clockwise.
The On/Off switch
Fig. A
• Switch the machine on by pressing the On/Off
switch (5). When you release the On/Off switch
(5) the machine will turn off.
• The rotation-speed can be adjusted by
pressing the On/Off switch (5) harder for
raising the rotation-speed or release pressure
for lowering the rotation-speed.
Lock-on Button
Fig. A
• You can lock the On/Off switch (5) by pressing
the On/Off switch (5) and then pressing the
lock-on button (4).
• To release the switch-lock; shortly press the
On/Off switch (5) again.
Adjusting of the maximum rotation speed
Fig. A
• Switch the machine on by pressing the On/Off
switch (5).
• Lock the On/Off switch (5) by pressing the
lock-on button (4).
