7

EN

Gear selection

Fig. B

Two mechanical speed ranges can be selected
with the gear selector switch (4):
Gear 1       180-400/min
Gear 2       300-700/min

The necessary gear depends on the type of the
material mixed and it is recommended to verify it
by a practical test.

Speed adjustment

Fig. B

The required speed can be adjusted by using
the Speed adjustment wheel (3). Also during
operation the rotational speed can be adjusted.
•   To increase the speed, turn the Speed

adjustment knob (3) clockwise.

•  To decrease the speed, turn the Speed

adjustment knob (3) anti-clockwise. The
required speeds depends on the material and
can be determined by practical testing.

Optimum use

•  For materials with low viscosity, e.g.

emulsion paint, varnishes, adhesive, grouting
compound and cement slurry, a stirrer
whisk with a so-called left-hand spiral is
recommended for optimum use. With a left-
hand spiral, the material is moved from the top
downwards and the stirrer whisk is pushed
upwards. Materials with low viscosity are
mixed in a way which minimises splattering,
so a low speed is recommended (gear 1).

•  For materials with high viscosity, e.g. plaster,

concrete, cement, screed, filler and epoxy
resin, a stirrer whisk with a so-called right-
hand spiral is recommended for optimum use.
With a right-hand spiral, the material is moved
from the bottom upwards and the stirrer whisk
is pulled downwards (working its way into
the mixture). Materials with high viscosity
are mixed thoroughly, so a high speed is
recommended (gear 2).

•  For optimum results, move the power tool in

an up and down motion while mixing.

•  It is recommended to clean the whisk after

use, for example by stirring the whisk in a
bucket filled with water.

5. MAINTENANCE

 Before cleaning and maintenance,
always switch off the machine and
remove the mains plug from the mains.

Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and
dirt. Remove very persistent dirt using a soft
cloth moistened with soapsuds. Do not use any
solvents such as gasoline, alcohol, ammonia,
etc. Chemicals such as these will damage the
synthetic components.

ENVIRONMENT

 Faulty and/or discarded electrical or
electronic apparatus have to be collected
at the appropriate recycling locations.

Only for EC countries

Do not dispose of power tools into domestic
waste. According to the European Guideline
2012/19/EU for Waste Electrical and Electronic
Equipment and its implementation into national
right, power tools that are no longer usable must
be collected separately and disposed of in an
environmentally friendly way.

WARRANTY

FERM products are developed to the highest
quality standards and are guaranteed free of
defects in both materials and workmanship for
the period lawfully stipulated starting from the
date of original purchase. Should the product
develop any failure during this period due to
defective material and/or workmanship then
contact your FERM dealer directly.
The following circumstances are excluded from
this guarantee:
•   Repairs and or alterations have been made

or attempted to the machine by unauthorized
service centers.

•   Normal wear and tear.
•   The tool has been abused, misused or

improperly maintained.

•   Non-original spare parts have been used.
