Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool.

 Power tools are dangerous in the hands

of untrained users.

BRIEF DESCRIPTION

The mixer is used to mix liquid products, such as
mortar, adhesive paste, paints epoxy resins, cement
and similar products.

Its use is not permitted for food products or similar ones.

The mixer is not adequate for mixing materials that con-
tain powdered graphite, liquid manure or salt solution,
since these materials may seriously damage the machine.

Optimum mixer performance depends on the density of
the product to be employed and amount to be mixed, the
correct mechanism must be used for each situation.

1. Suppression of torsional stress (Fig. 4)

The opposite rotation direction of the whisks provides
more stability and less work effort because it counteracts
the torsional stress created by each whisk.

2. Mixing action (Fig. 4)

The geometry of the whisks allows the mixing of all
types of materials and, in particular, of solid and very
dense materials.

BEFORE USING THIS TOOL

Make sure the mains voltage is correct: it must be the
same as that on the specification label. Machines with
230V can also be connected to a 220-V mains supply.

Only clean inserting rods should be used.

The rods should be introduced into the Quick Fix

G

Adapter until they become self-blocking.

Upon installing the rods, take into account the adjust-
ment of the mixing blades. The mixing blades may not
come into contact.

During the assembly, pay close attention to the colors
that the whisks coincide with the shafts. The colors of
the whisks have to coincide in order to function cor-
rectly, because one whisk spins

clockwise

 and the

other whisk spins

counter clockwise

; the red whisk

must coincide with the red adaptor and the black one
with the black adaptor.

The mix effect can be inverted by swapping whisks. This
can have a positive affect in the case of liquid materials,
but the machine is placed under more pressure.

START UP

WARNING!

 Only plug in when machine is switched off.

Press the locking button

A

, and squeeze the trigger in

the on/off switch

B

. When the on/off switch is released,

the machine stops.

For safety reasons, it is not possible to lock On/Off
switch

B

, instead it has to be pressed while the machine

is being used.

Installing the mixer rod (Fig.3):

Screw the

G

 adapter (5/8” thread) unto the machine

shaft; for this purpose use a fixed spanner situated on
the drill chuck spindle spanner

C

 and another one on the

adapter and tighten.

Pull back the retaining ring and place the clean whisk in
the tool organizer, matching up both “0” for the rod as
well as the retaining ring, until they are correctly in place.
Release the retaining ring.
Pull on the mixing rod to assure yourself that it is blocked.
In order to withdraw or change the mixing rod, push the
retaining ring of the tool holder backwards and remove
the mixing rod.

Mains connection
Warning!

 Connect only to a single-phase AC current

supply and only to the mains voltage specified on the
rating plate. Connection to sockets without earth protec-
tion is possible as the appliance features protective
class II insulation according to European Standard EN
60745. Radio interference suppression complies with the
European Standard EN 60745.

FUNCTIONS

Mechanical speed shift

Low speed: Lever

D

 should be at sign I on the head

High speed: Lever

D

 should be at sign II on the head.

Speed adjustments. Constant electronic performance

The regulation electronics provides continuous adjust-
ment of the revolutions and frequency in order to adapt
the machine to the type of material being mixed. Ad-
justment is made using the speed adjustment switch

F

,

which has 6 positions to regulate the speed.
The higher the number, the greater the speed. The
range of settings from “1” (low power) to “6” (full
power) makes the tool very flexible and adaptable to
different applications.
The constant speed control maintains the pre-set num-
ber of revolutions and impact frequency.

NOISE AND VIBRATION

This tool has been designed and made to reduce noise
to a minimum. However, in spite of this,

in certain

circumstances the maximum noise level in the place
of work could exceed 85 dBA. In this case, the op-
erator should wear ear protection.

The machine’s noise and vibration levels, measured in
compliance with EN 60745, usually reach:
Acoustic pressure = 92 dB(A)
Sound-power level = 105 dB(A)

Use ear protection!

Vibration acceleration = 12.7 m/s

2

MAINTENANCE AND CARE

WARNING

-Always unplug the machine before carrying

out work on it.

-

 The machine should be taken to a technical service

centre if the power falls.

-

Tool inspection:

 Using a worn tool will reduce the

efficiency of the work being performed and could
lead to motor damage and the tools should be
changed when any abrasion is noted.

Daily:

 Clean

the tool holder.

-

Inspect the mounting screws:

 Regularly inspect all

the mounting screws and ensure they are firmly tight-
ened. Should any screw be loose, tighten it immedi-
ately. Failure to do so could put you at serious risk.
