TECHNICAL DATA

Double rod mixer

MKF1200/VE2

MKF1600/VE2

Rated power

W

1200

1600

No load speed

rpm

120-450/245-825

105-420/215-865

Work shaft thread

ISO

5/8”x16

5/8”x16

Torque Nm

57/27

62/30

Mix volume

L

120

170

Approx. weight

kg

4.6

4.6


The instructions contained in this manual must be strictly
followed, it should be carefully read and kept close at
hand to use when carrying out maintenance on the
indicated parts.
If the machine is used carefully and normal maintenance
is carried out, it will work well for a long time.
The functions and use of the tool you have bought shall
be only those described in this manual.

Any other use

of the tool is strictly forbidden.

ILLUSTRATIONS

DESCRIPTION (See figures)


A

Safety push button switch (Fig.1)

B

On-/off switch (Fig.1)

C  Drill chuck shaft gap (Fig.1)
D  Mechanical speed shift lever (Fig.1)
E

Auxiliary grip (Fig.1)

F

Speed adjustment (Fig.1)

G  Quick Fix Adapter (Fig.1 and 3)
H  Mixing rod (Fig.1 and 2)

EQUIPMENT

-

  Quick Fix Adapter

-

  2 mixing rods

-

 Operating instructions

-

 Safety instructions

-

 Warranty

SAFETY INSTRUCTIONS



 See  “

Safety Instructions

” manual, supplied with this

instruction manual.



Warning!

 Follow the insurance company’s safety

instructions regarding the responsibility of employees.



 For your personal safety, always connect the machine

to a mains supply protected by a differential and ther-
mal cut-out switch, in accordance with regulations on
low-voltage wiring sitemaps.



 Do not perforate the machine casing, as this would

destroy the protective insulation (use adhesive labels).



 Always unplug the machine before doing any work on it.



Warning!

 Before each use, inspect the plug and

lead. Should they need replacing, have this done by
an official service centre. Only plug the machine in
when it is switched off.



 Always keep the lead out of the machine’s working area.



 Only plug the machine in when it is switched off.



 Do not allow the machine to get wet, nor should it be

used in wet environments.



 Hold the machine firmly by the handle and the auxiliary

handle, otherwise the machine could work imprecisely
or even dangerously.



 The machine must not be used at a location where a

danger of explosion exists.



 Solvents or products containing solvents must not be

mixed since there is a danger of igniting if the tempera-
ture exceeds 21ºC.



 Officially approved extension cables must be used for

outside operations.



 The machine should only be start and stopped inside a

container and this must be firmly fixed in place and
unable to move.



 Hands or other objects should not be inserted into the

container when working with the machine in operation.



 The machine should be inserted into or removed from

the container at a low speed, and once inside, speed
can be increased to maximum in order to prevent ma-
chine over-heating and it should be moved in all direc-
tions to guarantee thorough mixing.



Keep work area clean and well lit.

Cluttered and

dark areas invite accidents.



Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable liq-
uids, gases or dust.

Power tools create sparks which

may ignite the dust or fumes.



Keep-children and bystanders away while oper-
ating a power tool.

 Distractions can cause you to

lose control.



Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and re-
frigerators.

 There is an increased risk of electric

shock if your body is earthed or grounded.



Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.

 Damaged or entangled cords increase

the risk of electric shock.



When operating a power tool outdoors, use an
extension cord suitable for outdoor use.

 Use of

cord suitable for outdoor use reduces the risk of
electric shock.



Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication.

A

moment of inattention while operating power tools may
result in serious personal injury.



Use safety equipment. Always wear eye protection.

Safety equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appro-
priate conditions will reduce personal injuries.



Do not overreach. Keep proper footing and bal-
ance at all times.

This enables better control of the

power tool in unexpected situations.
