For your safety.
Read all safety warnings and all
instructions.
Failure to follow the
warnings and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference.
Do not use this power tool before you have thor-
oughly read and completely understood this
Instruction Manual and the enclosed “General
Safety Instructions” (document number
3 41 30 054 06 1). The documents mentioned should be
kept for later use and enclosed with the power tool,
should it be passed on or sold.
Please also observe the relevant national industrial safety
regulations.
Intended use of the power tool:
hand-held drill for drilling in metal, wood, plastic, ceram-
ics, and for tapping in weather-protected environments
using the application tools and accessories recommended
by FEIN.
This power tool is also suitable for use with AC genera-
tors with sufficient power output that correspond to the
Standard ISO 8528, design type G2. This Standard is par-
ticularly not complied with when the so-called distortion
factor exceeds 10 %. When in doubt, please refer to the
generator instruction/specification guide.
Special safety instructions.
Use auxiliary handle(s), if supplied with the tool.
Loss of
control can cause personal injury.
Hold power tool by the insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord.
Cutting acces-
sory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the opera-
tor an electric shock.
Secure the work piece firmly.
A work piece that is
gripped tightly in a clamping device or vice, is more
secure than if held by hand.
Hold the power tool firmly.
High reaction torque can
briefly occur.
Beware of any concealed electric cables, gas or water
conduits.
Check the working area before commencing
work, e. g. with a metal detector.
Do not work materials containing magnesium.
Danger of
fire.
Do not work CFP (carbon-fiber-reinforced polymer) and
materials containing asbestos.
These materials are con-
sidered carcinogenic.
Do not direct the power tool against yourself, other per-
sons or animals.
Danger of injury from sharp or hot
application tools.
n
0
/min, min
-1
, rpm, r/min rpm
Rated speed
M...
mm
mm
Size of metric thread
Ø
mm
mm
Diameter of a round part
mm
mm
Drilling diameter, steel
mm
mm
Drilling diameter, aluminium
mm
mm
Tap
mm
mm
Diameter for reaming
mm
mm
d1 = Clamping range of drill chuck
d2 = Shank size of drilling shaft
d3 = Collar diameter
kg
kg
Weight according to EPTA-Procedure 01
T
a
°C
°C
Allowable ambient temperature
L
pA
dB
dB
Sound pressure level
L
wA
dB
dB
Sound power level
L
pCpeak
dB
dB
Peak sound pressure level
K...
Uncertainty
m/s
2
m/s
2
Vibrational emission value according to
EN 60745 (vector sum of three directions)
h,D
m/s
2
m/s
2
Mean vibrational value for drilling in metal
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
min, m/s
2
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
min, m/s
2
Basic and derived units of measurement from
the international system of units
SI
.
Character
Unit of measurement,
international
Unit of measurement,
national
Explanation
Fe
Al
WARNING
