18

en

Use only intact original FEIN batteries that are intended
for your power tool.

When working with and charging

incorrect, damaged, repaired or reconditioned batteries,
imitations or other brands, there is danger of fire and/or
explosion.

Follow the safety warnings in the operating instructions
of the battery charger.

Hand/arm vibrations

The vibration emission level given in this information
sheet has been measured in accordance with a standard-
ised test given in EN 60745 and may be used to compare
one tool with another. It may be used for a preliminary
assessment of exposure.
The declared vibration emission level represents the
main applications of the tool. However, if the tool is used
for different applications, with different accessories or
poorly maintained, the vibration emission may differ.
This may significantly increase the exposure level over
the total working period.
An estimation of the level of exposure to vibration
should also take into account the times when the tool is
switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total working period.
Identify additional safety measures to protect the opera-
tor from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of work patterns.

Handling hazardous dusts

For work procedures with this power tool where mate-
rial is removed, dusts develop that can be hazardous to
one’s health.
Contact with or inhaling some dust types, e. g. asbestos
and asbestos-containing materials, lead-containing coat-
ings, metal, some wood types, minerals, silicate particles
from materials containing stone, paint solvents, wood
preservatives, antifouling paints for vessels, can trigger
allergic reactions to the operator or bystanders and/or
lead to respiratory infections, cancer, birth defects or
other reproductive harm. The risk from inhaling dusts
depends on the exposition. Use dust extraction matched
appropriately for the developing dust, as well as personal
protective equipment and provide for good ventilation of
the workplace. Leave the processing of asbestos-contain-
ing materials to specialists.
Wood and light-metal dust, hot mixtures of sanding dust
and chemical materials can self-ignite under unfavourable
conditions or cause an explosion. Avoid sparking in the
direction of the dust collector as well as overheating of the
power tool and the materials being sanded, empty the dust
collector/container in time, observe the material manufac-
turer’s working instructions, as well as the relevant regula-
tions in your country for the materials being worked.

Operating Instructions.

Change the gear setting or the rotation direction only
after the motor has come to a complete stop.
To avoid accidental starting, e. g., during transport, set
the rotation selector switch to the centre position.
When overheated, the machine runs with short, low-
power impulses. Allow the machine to cool down at no-
load speed.

For stationary use in a drill stand, remove the switched off
power tool from the drill stand every 50 operating hours
while at normal running temperature. Then, turn the
machine around by 180 °  to achieve uniform lubrication.

AWBP10:

Degrease the output spindle and the inside

cone of the drill chuck before mounting.

Handling the battery.

Operate and charge the battery only within the battery
operating-temperature range of 0 °C – 45 °C (32 °F –
113 °F). At the beginning of the charging procedure, the
battery temperature must be within the battery operat-
ing-temperature range.

The real percentage of the battery charge condition is
only indicated when the power tool motor is stopped.
The electronics automatically switch off the motor prior
to the battery being deep discharged.

Repair and customer service.

When working metal under extreme operat-
ing conditions, it is possible for conductive
dust to settle in the interior of the power tool.

Blow out the interior of the power tool via the ventila-
tion slots frequently with dry and oil-free compressed air.
The current spare parts list for this power tool can be
found in the Internet at www.fein.com.

If required, you can change the following parts yourself:

Drill chuck, auxiliary handle, application tools, battery

Warranty and liability.

The warranty for the product is valid in accordance with
the legal regulations in the country where it is marketed.
In addition, FEIN also provides a guarantee in accordance
with the FEIN manufacturer’s warranty declaration.
The delivery scope of your power tool may include only
a part of the accessories described or shown in this
Instruction Manual.

Declaration of conformity.

FEIN declares itself solely responsible for this product
conforming with the relevant provisions given on the last
page of this Instruction Manual.
Technical documents at: C. & E. Fein GmbH, C-DB_IA,
D-73529 Schwäbisch Gmünd

Environmental protection, disposal.

Packaging, worn out power tools and accessories should
be sorted for environmental-friendly recycling.
Dispose of batteries only when discharged.
For batteries that are not completely discharged, insulate
the terminals with tape as a protective measure against
short-circuiting.

LED indicator Meaning

Activity

1 – 4 green
LED

Percentage of
charge condition

Operation

Continuous
red light

Battery is almost
empty

Charge battery

Red flashing
light

Battery is not
ready for opera-
tion

Bring the battery into
the battery operat-
ing-temperature
range, then charge
