Limit the operating time.

All stages of the operating cycle must be conside-

red (for example, times in which the electric tools

are switched off and times in which the tool is

switched on but operates without load).

5. Before starting the equipment

Be sure to read the following information before

you use your cordless screwdriver for the first

time:

1.  Only ever use sharp drill bits and screwdriver

bits which are suitable for the purpose and in

faultless condition.

2.  Always check for concealed electric cables

and gas and water pipes when drilling and

screwing in walls.

6. Operation

6.1  Charging the LI battery pack (Fig. 2-3)

1.  Remove the battery pack (5) from the handle,

pressing the pushlock buttons (8) downwards

to do so.

2.  Check that your mains voltage is the same as

that marked on the rating plate of the battery

charger. Insert the power plug of the charger

(6) into the mains socket outlet. The green

LED will then begin to flash.

3.  Push the battery pack onto the battery char-

ger.

In section 10 “Charger indicator” you will find a

table with an explanation of the LED indicator on

the charger.

If the battery pack fails to become charged, ple-

ase check

•

 whether there is voltage at the socket-outlet

•

 whether there is proper contact at the char-

ging contacts on the charger.

If the battery still fails to become charged, please

return

•

 the  charger

•

 the battery pack

to our Customer Service Department.

To ensure that items are properly packaged

and delivered when you send them to us,

please contact our customer service or the

point of sale at which the equipment was

purchased.

When shipping or disposing of batteries and

cordless tools, always ensure that they are

packed individually in plastic bags to prevent

short circuits and fires.

To ensure that the battery pack provides long ser-

vice, you should take care to recharge it promptly.

You must recharge the battery pack when you

notice that the performance of the device drops.

Never allow the battery pack to become fully di-

scharged. This will cause it to develop a defect.

6.2  Torque setting (Fig. 4 / Item 1)

Important! The tool must be at a standstill

when you set the torque with the setting ring.

The cordless screwdriver is fitted with a mechani

-

cal torque selector.

The torque for a specific size of screw is selected

with the set-collar (1). The correct torque depends

on several factors:

•

 on the type and hardness of material in ques-

tion

•

 on the type and length screws used

•

 on the requirements needing to be met by the

screwed joint.

The clutch disengages with a grating sound to

indicate when the set torque is reached.

6.3  Drilling (Fig. 4/Item 1)

For drilling purposes, adjust the setting ring for

the torque to the last setting “Drill”. In the drill

setting the slip coupling is non-functional. The

maximum torque is available for drilling.

Important! Change the torque setting (1) and

the selector switch for driving/drilling/impact

drilling (11) only when the equipment is at a

standstill.

6.4  Forward/Reverse switch (Fig. 5 / Item 3)

With the slide switch above the On/Off switch you

can select the direction of rotation of the battery-

powered drill/screwdriver and secure it against

being switched on accidentally. You can choose

between clockwise and anticlockwise rotation. To

avoid causing damage to the gearing it is advisa-

ble to change the direction of rotation only when

the tool is at a standstill. The On/Off switch is blo

-

cked when the slide switch is in centre position.
