English

Installing and Removing Attachments
(Fig. A, D)

WARNING:

 Shock hazard. Under no circumstances should

this product be used near water.

WARNING:

 Burn hazard. Moving parts within the

power unit become hot during use. Avoid contact with
moving parts within power unit when removing and
installing accessories.

WARNING:

 Before assembly, lock the power unit by

setting the forward/reverse slider to the center position
and remove the battery from the tool. Remove any
accessory from the attachment before removing or
installing the attachment.

1.  Pull back on the locking sleeve

 18

 on the attachment in the

direction of the arrow.

2.  Slide the attachment onto the spindle

 19

, aligning the

slots

 20

 on the attachment with the lugs

 21

 around

the spindle.

nOTE:

Once on the spindle you may have to rotate the

attachment a small bit side to side so the slots align with
the lugs. The 10 mm chuck attachment

 8

 does not have

any slots to align.

3.  To remove the attachment, pull back on the locking sleeve

in the direction of the arrow and remove the attachment
from the spindle.

nOTE:

The 6.35 mm hex right angle attachment

 9

 allows

additional attchments to be installed on its spindle. With
the 6.35 mm hex right angle attachment installed on the
tool follow instruction 1 and 2 of this section to install
additional attachments.

nOTE:

Only use attachments that are specifically designed

for and compatible with the power unit. Refer to individual
attachment instruction manuals for specific safety warnings and
operating instructions before operating attachments with the
power unit.

Belt Hook (Fig. C)

Included with Some Models

WARNING: To reduce the risk of serious personal
injury, ONLY use the tool's belt hook to hang the
tool from a work belt. DO NOT

 use the belt hook for

tethering or securing the tool to a person or object during
use. DO NOT suspend tool overhead or suspend objects
from the belt hook.

WARNING: To reduce the risk of serious personal
injury,

ensure the screw holding the belt hook is secure.

iMPORTAnT:

When attaching or replacing a belt hook, use only

the screw that is provided. Be sure to securely tighten the screw.
A belt hook

 15

 can be be attached to either side of the tool

using only the screw

 16

 provided, to accommodate left‑ or

right‑handed users. If the belt hook is not desired at all, it can be
removed from the tool.
To move the belt hook, remove the screw

 16

 that holds it in

place then reassemble on the opposite side. Be sure to securely
tighten the screw.

Inserting and Removing the Battery Pack
from the Tool (Fig. B)

nOTE:

 Make sure your battery pack

 1

 is fully charged.

To Install the Battery Pack into the Tool Handle

1.  Align the battery pack

 1

 with the rails inside the tool’s

handle (Fig. B).

2.  Slide it into the handle until the battery pack is firmly seated

in the tool and ensure that you hear the lock snap into place.

To Remove the Battery Pack from the Tool

1.  Press the release button

 2

 and firmly pull the battery pack

out of the tool handle.

2.  Insert battery pack into the charger as described in the

charger section of this manual.

Fuel Gauge Battery Packs (Fig. B)

Some

D

e

WALT

 battery packs include a fuel gauge which

consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
To actuate the fuel gauge, press and hold the fuel gauge
button

 13

. A combination of the three green LED lights will

illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to be recharged.

nOTE:

The fuel gauge is only an indication of the charge left on

the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑user application.

ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start‑up can cause injury.

WARNING:

 Use only

D

e

WALT

 battery packs and chargers.

DO nOT

use under wet conditions or in the presence of

flammable liquids or gases.
These drills/drivers are professional power tools.

DO nOT

 let children come into contact with the tool.

Supervision is required when inexperienced operators use
this tool.
•

Young children and the infirm.

This appliance is not

intended for use by young children or infirm persons
without supervision.

•  This product is not intended for use by persons (including

children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.
