Do not incinerate the battery pack.

Battery Type

TheDCD701/DCD706 operate on a 12 volt battery pack.
These battery packs may be used: DCB122, DCB124, DCB125,
DCB127. Refer to

Technical Data

 for more information.

Package Contents

The package contains:
1  Drill/driver (DCD701)
 or
1  Hammerdrill (DCD706)
1 Charger
1  Belt hook (included with some models)
1  Li-Ion battery pack (C1, D1, L1 models)
2  Li-Ion battery packs (C2, D2, L2 models)
3  Li-Ion battery packs (C3, D3, L3 models)
1  Instruction manual

nOTE:

 Battery packs, chargers and kitboxes are not included

with N models. Battery packs and chargers are not included with
NT models.

nOTE:

 Trademarks and trade names are those of their

respective owners.

•  Check for damage to the tool, parts or accessories which may

have occurred during transport.

•  Take the time to thoroughly read and understand this manual

prior to operation.

Markings on Tool

The following pictograms are shown on the tool:

Read instruction manual before use.

Wear ear protection.

Wear eye protection.

Visible radiation. Do not stare into light.

Date Code Position (Fig. A)

The date code

 13

, which also includes



the year of manufacture,

is printed into the housing.
Example:

2019 XX XX

Year of Manufacture

Description (Fig. A)



WARNING:

Never modify the power tool or any part of it.

Damage or personal injury could result.

Battery pack

Battery pack release button

Main handle

Variable speed trigger

Forward/reverse control button

Mode selection collar

Speed selector

Worklight

Chuck sleeve

10

Keyless chuck

Intended Use

These drills/drivers/hammerdrills are designed for professional
drilling, percussion drilling and screwdriving applications.

DO nOT

use under wet conditions or in the presence of

flammable liquids or gases.
These drills/drivers/hammerdrills are professional power tools.

DO nOT

 let children come into contact with the tool.

Supervision is required when inexperienced operators use
this tool.
•

Young children and the infirm.

 This appliance is not

intended for use by young children or infirm persons
without supervision.

•  This product is not intended for use by persons (including

children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.

ASSEMBLY AND ADJUSTMENTS



WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start-up can cause injury.



WARNING:

Use only

D

e

WALT

 battery packs and chargers.

Inserting and Removing the Battery Pack

from the Tool (Fig. B)

nOTE:

 Make sure your battery pack

 1

 is fully charged.

To Install the Battery Pack into the Tool Handle

1.  Align the battery pack

 1

 with the rails inside the tool’s

handle (Fig. B).

2.  Slide it into the handle until the battery pack is firmly seated

in the tool and ensure that you hear the lock snap into place.

To Remove the Battery Pack from the Tool

1.  Press the release button

 2

 and firmly pull the battery pack

out of the tool handle.

2.  Insert battery pack into the charger as described in the

charger section of this manual.

Fuel Gauge Battery Packs (Fig. B)

Some

D

e

WALT

 battery packs include a fuel gauge which

consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
