9

CORDLESS DRILL/DRIVER

EN

Battery charge

ATTENTION!

The charger should only be connected to a single phase AC power network, the voltage of

which corresponds to the voltage indicated on the label.

Plug the charger into wall outlet. In 1…2 s indicator 16 (pic. 1) of the charger glows green, which indicates
readiness for work.
Install the rechargeable battery into the charger guides until it stops, do not put much effort. If the battery is not
installed on the charger without much effort, check that the charger and battery match the rated voltage and
model. If the battery is low or not fully charged, charger indicator 16 (pic. 1) will change the color of the glow from
green to red, which indicates the ongoing process of charging. Battery indicator 12 (pic. 1) will flash, reflecting the
charging process.
Upon reaching full battery charge the charger indicator 16 switches to green, the indicator on the battery will
glow without blinking.

ATTENTION!

Battery charging is possible at ambient temperatures from 0 °С to +40 °С. DO NOT charge the

battery when the ambient temperature is negative.

NOTE. Remember to turn off the charger when charging is complete.
Your tool is equipped with a lithium-ion rechargeable battery which does not have memory effect. Batteries of
this type are rechargeable.
Keep the battery charged at a temperature not lower than 0 °С.
NOTE. New battery can reach its rated capacity after two or three charge-discharge cycles.
Battery charge level can be estimated using the indicator 12 (pic. 1) located on the battery case. The indicator
turns on when you press the button 11 (pic. 1) and turns off automatically after 3..4 sec. The glow of the three
elements of the indicator indicates a full battery, if one glows then the charge is about 30% and it is time to charge
the battery.

Reversal of rotation

ATTENTION!

The reversal of rotation must be done only when the engine is off. It is forbidden to switch the

direction of rotation while the machine is running.

The direction of rotation of the spindle is changed by the switch 4 (pic. 1). The switch has 3 fixed positions. When
you press the switch on the right until it stops– right-hand spindle rotation is activated, when press to the left
– left-hand. Corresponding symbols are printed on the movable switch bar. The middle position of the switch
corresponds to the lock of the engine switch, at the same time, when you press the switch the power does not
move to the motor, and only the work area illumination turns on.

Speed adjustment

The switch of the tool 9 (pic. 1) allows you to increase the speed of rotation from zero to maximum smoothly.
Rotational speed depends on the degree of pressure on the switch, the greater the degree of pressing on the
switch – the higher the speed of the chuck.
The machine is equipped with an electric spindle lock; it allows you to almost instantly stop the spindle when
you release the switch. Electric brake operation may be accompanied by a spark discharge visible through the
ventilation holes of the tool case. In this regard, the spark discharge in the tool engine, caused by abruptly
releasing the switch, is not a sign of any malfunction.
