Installation and regulation of power tool

elements

Before carrying out any works on the power tool it

must be disconnected from the mains.

Do  not  draw  up  the  fastening  elements

too tight to avoid damaging the thread.

Mounting  /  dismounting  /  setting-up  of

some elements is the same for all power

tool models, in this case specific models

are not indicated in the illustration.

Additional handle (see fig. 1)
[CT10127, CT10127C, CT10127-13, CT10127-13C]

Always use the additional handle

8

 when operating�

Additional handle

8

 may be positioned as deemed

comfortable by the user�

Mount / dismount additional handle

8

 as shown on

fig. 1.

Mounting  /  replacement  of  accessories  (see

fig. 2-4)

With  long-term  use  the  drill  bit  may  be-

come very warm; use gloves to remove it.

Gear rim chuck (see fig. 2)
[CT10125,  CT10126,  CT10143,  CT10143-13,

CT10127, CT10127-13]

•

Release the cams grip with drill chuck key

9

, then

rotate the quill of gear rim chuck

1

 counter-clockwise

with  your  hand  (see  fig.  2)  until  the  cams  move  apart

at the distance allowing an accessory to be mounted /

replaced�

•

Mount / replace an accessory�

•

Rotate the quill of gear rim chuck

1

 clockwise with

your hand in order to lock the accessory mounted� Do

not allow the accessory to become distorted�

•

Tighten the cams of gear rim chuck

1

 with drill chuck

key

9

 applying a similar torque to each of the three

openings on the side surface of the chuck�

Keyless chuck (see fig. 3)
[CT10125C, CT10126C, CT10143C, CT10127C]

•

Open the jaws of the keyless chuck

10

 - hold its rear

part with one hand and rotate its front part with the

other hand as it is shown in figure 3.

•

Mount / replace the accessory�

•

Tighten the keyless chuck

10

 without skewing the

accessory as it is shown in figure 3.

Keyless chuck (with lock) (see fig. 4)
[CT10143-13C, CT10127-13C]

•

Move the clutch in the back part of keyless chuck

(with lock)

11

 back until it clicks into position (see fig. 4).

•

Open the jaws of the keyless chuck (with lock)

11

 -

hold its rear part with one hand and rotate its front part

with the other hand as it is shown in figure 4.

•

Mount / replace the accessory�

•

Tighten the keyless chuck (with lock)

11

 without

skewing the accessory as it is shown in figure 4.

•

To  fix  the  lock,  move  the  clutch  in  the  back  part  of

keyless chuck (with lock)

11

 forward until it clicks into

position�

Mounting  /  dismounting  of  the  drill  chuck  (see

fig. 5-10)

•

To mount the gear rim chuck

1

, carry out the op-

erations  in  consecutive  stages  as  it  is  shown  in  fig

-

ure 5�

•

To dismount the gear rim chuck

1

, carry out the

operations in consecutive stages as it is shown in fig

-

ure 6�

•

The mounting or dismounting of keyless chuck

10

 is

done is a similar way, see fig. 7-8.

•

The mounting or dismounting of keyless chuck (with

lock)

11

 is done is a similar way, see fig. 9-10.

Attention:  keep  in  mind  that  in  the  pro-

cess  of  mounting  /  dismounting  of  the

drill  chuck  the  screw  12  has  a  left-hand

thread.

Screwdriver bit / magnetic holder (see fig. 11)

When using the power tool as a screwdriver, use

magnetic holder

14

 for reliable locking of screwdriv-

er bits

13

  (see  fig.  11).  A  magnetic  holder

14

 is not

needed for extended screwdriver bits

13

 (specially pur-

posed for screwdrivers)�

Initial operating of the power tool

Always use the correct supply voltage: the power sup-

ply voltage must match the information quoted on the

power tool identification plate.

Switching the power tool on / off

Short-term switching on / off

To switch on, press and hold on / off switch

6

, to switch

off - release it�

Long-term switching on / off
Switching on:

Push on / off switch

6

 and lock it in the position with

lock-on button

5

�

Switching off:

Push and release on / off switch

6

�

Design features of the power tool

Stepless speed adjustment

Speed is controlled from 0 to maximum by

pressing force of on / off switch

6

� Weak

pressing results in low revolutions, which

enable a smooth power tool switch-on�
