 English |

13

Bosch Power Tools

2 610 016 854 | (20.9.11)

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

While reading the operating instructions, unfold the graphics

page for the machine and leave it open.

Intended Use

The machine is intended for driving in and loosening screws

as well as for drilling in wood, metal, ceramic and plastic, es-

pecially at hard to reach locations.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1

“PowerLight”

2

Keyless chuck

3

Rotational direction switch

4

On/Off switch

5

Release button for angle selection of drill head

6

Battery charge-control indicator

7

Battery unlocking button *

8

Battery *

9

Handle (insulated gripping surface)

10

Screwdriver bit *

11

Universal bit holder *

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product

is 72 dB(A). Uncertainty K = 3 dB.

The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

Drilling into metal: a

h

= 3.5 m/s

2

, K = 1.5 m/s

2

,

Screwdriving: a

h

= 3.5 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

sure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

riod.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents: EN 60745

according to the provisions of the directives 2011/65/EU,

2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:

Robert Bosch GmbH, PT/ETM9,

D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

20.09.2011

Assembly

Battery Charging (see figure A)

f

Use only the battery chargers listed on the accessories

page.

Only these battery chargers are matched to the lith-

ium ion battery of your power tool.

Cordless angle drill/driver

GWB 10,8-LI

Professional

Article number

3 601 C90 9..

Rated voltage

V=

10.8

No-load speed

min

-1

0 – 1 300

Max. torque for hard/soft screw-

driving application according to

ISO 5393

Nm

11 / 3

Max. screw dia.

mm

6

Max. drilling dia.

– Steel

– Wood

mm

mm

10

10

Weight according to

EPTA-Procedure 01/2003

kg

1.2

Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.

Dr. Egbert Schneider

Senior Vice President

Engineering

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI
