English |
19
Bosch Power Tools
1 609 929 M17 | (5.9.07)
Declaration of Conformity
We declare under our sole responsibility that the
product described under “Technical Data” is in
conformity with the following standards or
standardization documents: EN 60745 according
to the provisions of the directives 2004/108/EC,
98/37/EC (until Dec. 28, 2009), 2006/42/EC
(from Dec. 29, 2009 on).
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
31.07.2007, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Assembly
Auxiliary Handle (see figure A)
f
Operate your machine only with the auxiliary
handle 10.
The auxiliary handle
10
can be set to any position
for a secure and low-fatigue working posture.
Turn the bottom part of the auxiliary handle
10
in
counterclockwise direction and swivel the auxil-
iary handle
10
to the desired position. Then
retighten the bottom part of the auxiliary handle
10
by turning in clockwise direction.
Adjusting the Drilling Depth (see figure A)
The required drilling depth
X
can be set with the
depth stop
11
.
Press the button for the depth stop adjustment
9
and insert the depth stop into the auxiliary han-
dle
10
.
Pull out the depth stop until the distance be-
tween the tip of the drill bit and the tip of the
depth stop correspond with the desired drilling
depth
X
.
The knurled surface of the depth stop
11
must
face upward.
Changing the Tool
f
Before any work on the machine itself, pull
the mains plug.
Keyless Chuck (see figure B)
The drill spindle is locked when the On/Off
switch
5
is not pressed. This makes quick, con-
venient and easy changing of the tool in the drill
chuck possible.
Open the keyless chuck
1
by turning in rotation
direction
n
, until the tool can be inserted. Insert
the tool.
Firmly tighten the collar of the keyless chuck
1
by
hand in rotation direction
o
until the locking ac-
tion (“click”) is no longer heard. This automati-
cally locks the chuck.
The locking is released again to remove the tool
when the collar is turned in the opposite direc-
tion.
Key Type Drill Chuck (see figure C)
f
Wear protective gloves when changing the
tool.
The drill chuck can become very hot dur-
ing longer work periods.
Open the key type drill chuck
13
by turning until
the tool can be inserted. Insert the tool.
Insert the chuck key
12
into the corresponding
holes of the key type drill chuck
13
and clamp the
tool uniformly.
Screwdriver Tools (see figure D)
When working with screwdriver bits
14
, a univer-
sal bit holder
15
should always be used. Use only
screwdriver bits that fit the screw head.
For driving screws, always position the “Drill-
ing/Impact Drilling” selector switch
2
to the
“Drilling” symbol.
Replacing the Drill Chuck
f
Before any work on the machine itself, pull
the mains plug.
f
For power tools without spindle lock, the
drill chuck must be replaced by an author-
ised after-sales service agent for Bosch pow-
er tools.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
