20
| English
2 609 140 816 | (26.10.10)
Bosch Power Tools
Assembly
Battery Charging
f
Use only the battery chargers listed on the
accessories page.
Only these battery charg-
ers are matched to the lithium ion battery of
your power tool.
Note:
The battery is supplied partially charged.
To ensure full capacity of the battery, complete-
ly charge the battery in the battery charger be-
fore using your power tool for the first time.
The lithium ion battery can be charged at any
time without reducing its service life. Interrupt-
ing the charging procedure does not damage the
battery.
The lithium ion battery is protected against
deep discharging by the “Electronic Cell Protec-
tion (ECP)”. When the battery is empty, the ma-
chine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
Do not continue to press the
On/Off switch after the ma-
chine has been automatically switched off.
The
battery can be damaged.
The battery is equipped with a NTC temperature
control which allows charging only within a tem-
perature range of between 0 ° C and 45 ° C. A
long battery service life is achieved in this man-
ner.
Observe the notes for disposal.
Removing the Battery
The battery
5
is equipped with two locking lev-
els that should prevent the battery from falling
out when pushing the battery unlocking button
6
unintentionally. As long as the battery is in-
serted in the power tool, it is held in position by
means of a spring.
To remove the battery
5
, press the unlocking
button
6
and pull out the battery toward the
front.
Do not exert any force.
Cordless Impact Screwdriver
GDS 14,4 V-LI
Professional
GDS 18 V-LI
Professional
Article number
3 601 JA1 T.. 3 601 JA1 T.. 3 601 JA1 S.. 3 601 JA1 S..
with battery
“premium”
“compact”
“premium”
“compact”
Rated voltage
V=
14.4
14.4
18
18
No-load speed
min
-1
0 – 2 800
0 – 2 800
0 – 2 800
0 – 2 800
Impact rate
min
-1
0 – 3 200
0 – 3 200
0 – 3 200
0 – 3 200
Maximum torque, hard
screwdriving application ac-
cording to ISO 5393
Nm
170
170
180
180
Bolt size
mm
M6 – M16
M6 – M16
M6 – M16
M6 – M16
Tool holder
½"
½"
½"
½"
Weight according to
EPTA-Procedure 01/2003
kg
1.6
1.4
1.7
1.5
Please observe the article number on the type plate of your machine. The trade names of the individual machines
may vary.
WARNING
