16

 | English

The vibration level and noise emission value given in these

instructions have been measured in accordance with a

standardised measuring procedure and may be used to com-

pare power tools. They may also be used for a preliminary

estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-

ent the main applications of the power tool. However, if the

power tool is used for other applications, with different ap-

plication tools or is poorly maintained, the vibration level

and noise emission value may differ. This may significantly

increase the vibration and noise emissions over the total

working period.
To estimate vibration and noise emissions accurately, the

times when the tool is switched off or when it is running but

not actually being used should also be taken into account.

This may significantly reduce vibration and noise emissions

over the total working period.
Implement additional safety measures to protect the oper-

ator from the effects of vibration, such as servicing the

power tool and application tools, keeping their hands warm,

and organising workflows correctly.

Assembly

u

Remove the battery from the power tool before carry-

ing out work on the power tool (e.g. maintenance,

changing tool, etc.). The battery should also be re-

moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

Charging the Battery

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of

your power tool.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger

before using your power tool for the first time.
The lithium-ion battery can be charged at any time without

reducing its service life. Interrupting the charging process

does not damage the battery.
The lithium-ion battery is protected against deep discharge

by the "Electronic Cell Protection (ECP)". When the battery

is discharged, the power tool is switched off by means of a

protective circuit: The application tool no longer rotates.

u

Do not continue to press the On/Off switch after the

power tool has automatically switched off.

 The battery

can be damaged.

Removing the battery

To remove the battery , press the battery release button and

pull the battery to the rear and out of the power tool.

Do not

use force to do this.

Changing the tool (see figure A)

u

The application tool may heat up significantly during

operation.

 Allow it to cool down before touching it.

The drill spindle is locked when the on/off switch

(10)

 is not

pressed. This makes it possible to change the application

tool in the drill chuck quickly, conveniently and easily.
Open the keyless chuck

(2)

 by turning it in the direction of

rotation

➊

 until the tool can be inserted. Insert the tool.

Firmly tighten the sleeve of the keyless chuck

(2)

 by turning

it by hand in the rotational direction

➋

 until it stops clicking.

This will automatically lock the drill chuck.

Dust/Chip Extraction

Dust from materials such as lead-containing coatings, some

wood types, minerals and metal can be harmful to one’s

health. Touching or breathing-in the dust can cause allergic

reactions and/or lead to respiratory infections of the user or

bystanders.
Certain dust, such as oak or beech dust, is considered carci-

nogenic, especially in connection with wood-treatment ad-

ditives (chromate, wood preservative). Materials containing

asbestos may only be worked by specialists.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the ma-

terials to be worked.

u

Avoid dust accumulation at the workplace.

Dust can

easily ignite.

Operation

Starting Operation

Inserting the battery
Note:

 The use of batteries unsuitable for your power tool can

lead to malfunctions or damage to the power tool.
Set the rotational direction switch

(9)

 to the middle position

to avoid unintentionally switching it on. Insert the charged

battery

(7)

 into the handle until you feel it engage and it is

flush with the handle.

Setting the rotational direction (see figure B)

The rotational direction switch

(9)

 is used to change the ro-

tational direction of the power tool. However, this is not pos-

sible while the on/off switch

(10)

 is being pressed.

Right rotation:

 To drill and to drive in screws, press the ro-

tational direction switch

(9)

 through to the left stop.

Left rotation:

 To loosen and unscrew screws, press the ro-

tational direction switch

(9)

 through to the right stop.

Switching on/off

To

start

 the power tool, press and hold the on/off switch

(10)

.
