English |

25

facilitate identifying the set torque on a specific power tool.
Press the marking ring

(17)

 with a thin screwdriver blade, a

spatula or similar implement.
Always use the power tool with a marking ring to be certain
that the housing is protected against dust and dirt.

LED indicator

Battery charge indicator

If the battery

(11)

 needs to be charged, the

LED indicator

(10)

 flashes green and a sound

is emitted. You can only drive in six to eight

more screws.
If the LED indicator lights up red, there is not enough capa-
city left to drive in another screw or the power tool has over-
loaded. The power tool can no longer be switched on. The
lock-off function remains active until the drained battery has
been removed from the power tool and a charged battery in-
serted.
If you are working with a voltage adapter, the red LED

(10)

indicates overloading.
If the LED indicator

(10)

 flashes red, the power tool has

overheated and switched itself off. Wait a short while for the
light to stop flashing before switching the power tool on
again.
A significantly reduced operating time of the power tool after
charging indicates that the battery must be replaced soon.
Dispose of depleted batteries in accordance with legal/coun-
try-specific provisions.

Indicator for screwdriving applications

The shut-off clutch is triggered upon reaching
the preset torque. The LED indicator

(9)

 lights

up green.

If the preset torque has not been reached, the LED indicator

(9)

 lights up red and the tool emits a sound. The screw must

be driven in again.

Repeat protection

If the shut-off clutch is triggered while driving a screw, the
motor will switch off. You will need to wait 0.7 seconds be-
fore you can switch the tool on again. This prevents you from
accidentally retightening screws that are already firmly in
place.

Adjusting the angled screw head

ANGLE EXACT

2 | 3 | 6 | 7 | 8 | 15 | 17 | 23 | 30

You can adjust the angled screw head

(3)

 to a total of eight

different positions.
Hold the power tool with the open-ended spanner

(6)

against the spanner flat

(5)

 of the angled head flange.

u

Never clamp the power tool to the housing shells.

Loosen the cap nut with the open-ended spanner

(4)

 against

the spanner flat

(19)

. Move the angled screw head

(3)

 in 45°

degree increments into the required position and tighten the
cap nut again with the open-ended spanner

(4)

 against the

spanner flat

(19)

.

While doing this, place the open-ended spanner

(6)

 against

the angled head flange to hold it in place.

ANGLE EXACT

14CF | 22CF | 29CF

Observe the information for your purchased flat drive or ask
your dealer.

Adjusting the LED worklight (see figure J)

ANGLE EXACT

2 | 3 | 6 | 7 | 8 | 14CF | 15 | 17 |
22CF | 23 | 29CF | 30

Press the marking ring

(17)

 with a thin screwdriver blade, a

spatula or similar implement. Slide the spring ring

(33)

 back

onto the housing shell using a pair of spring ring pliers.
The two shell halves of the LED holder

(16)

 that encase the

LED worklight

(18)

 can now be brought into the required po-

sition. Taking care not to damage the cable on the LED work-
light, slide the cable into the cavity provided for it

(34)

 in the

housing shell without allowing it to bend. Encase the LED
worklight

(18)

 in the two housing shells of the LED holder

(16)

 once again.

Press the spring ring

(33)

 and the marking ring

(17)

 back

into their original position.

Maintenance and Service

Maintenance and Cleaning

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

Lubricating the power tool

Lubricant:

Special gearbox grease (225 ml)
Article number 3 605 430 009
Molykote grease
Motor oil SAE 10/SAE 20

– Clean the gearbox with a mild solvent after the first 150

operating hours. Follow the solvent manufacturer's in-
structions on use and disposal. Then lubricate the gear-
box with Bosch special gearbox grease. Repeat the clean-
ing process once every 300 operating hours after clean-
ing has been carried out for the first time.

– After driving 100,000 screws, oil the moving parts of the

shut-off clutch with a couple of drops of SAE 10/SAE 20
motor oil. Lubricate the sliding and rolling parts with Mo-
lykote grease. Use this occasion to check the clutch for
wear to ensure that accuracy and reproducibility have not
been affected. You will need to reset the clutch torque
once you have done this.

u

Have maintenance and repair work performed exclus-
ively by a qualified specialist.

 This will ensure that the

safety of the power tool is maintained.

An authorised Bosch after-sales service point will handle this
work quickly and reliably.
