Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
ANGLE EXACT
2 | 3 | 6 | 7 | 8 | 15 | 17 | 23 | 30
The power tool is intended for tightening and loosening
screws, bolts, nuts and other threaded connectors in the
specified power and dimension ranges.
The power tool is not intended for drilling; in order to pre-
vent personal injury and damage to property, power tools
with a shut-off clutch should never be used for drilling.
ANGLE EXACT
14CF | 22CF | 29CF
Due to its slow anti-clockwise rotation, the power tool is in-
tended for operation with an open flat drive. It is suitable for
working on screw connections that are only accessible from
one side,e.g. on pipelines.
It is not suitable for loosening screws.
The power tool is not intended for drilling; in order to pre-
vent personal injury and damage to property, power tools
with a shut-off clutch should never be used for drilling.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Application tool (e. g. nut driver bit)
(2)
Tool holder
(3)
Angled screw head
(4)
Open-ended spanner with width across flats of 27
mm
(5)
Spanner flat on angled head flange
(6)
Open-ended spanner with width across flats of 22
mm
(7)
Slider for preselecting the torque
(8)
Hanging hook
(9)
LED indicator for screwdriving applications
(10)
Battery charge LED indicator
(11)
Battery with contact APT
(12)
Battery release button
(13)
On/off switch
(14)
Rotational direction switch
(15)
Attachment slots for hanging hook
(16)
LED holder
(17)
Marking ring
(18)
Worklight
(19)
Spanner flat on the cap nut
(20)
Lock nut
(21)
Charger
(22)
Mains plug
(23)
Green LED indicator on the charger
(24)
Red LED indicator on the charger
(25)
Connection socket for a voltage adapter on the 4EX-
ACT
(26)
D-Sub connector plug
(27)
Screws on the D-Sub connector plug
(28)
Voltage adapter
(29)
Quick-change chuck
(30)
Adjustment tool
(31)
Hex key
(32)
Setting disc
(33)
Spring ring
(34)
Cavity in the housing shell
(35)
Handle (insulated gripping surface)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of ac-
cessories in our accessories range.
Technical data
ANGLE EXACT industrial cordless angle wrench
2
3
6
Article number
0 602 490 647
0 602 490 656
0 602 490 652
Max. torque, hard/soft screwdriving application accord-
ing to ISO 5393
Nm
2/2
3/3
6/6
No-load speed n
0
min
-1
110
420
650
Rated voltage
V
9.6
9.6
9.6
Direction of rotation
Weight according to EPTA-Procedure 01:2014
kg
1.0
1.0
1.0
Protection rating
IP 20
IP 20
IP 20
Bosch Power Tools
1 609 92A 4V1 | (05.03.2019)
