20

 BSB18G4

4811 66 01 XXXXXX MJJJJ

18 V

500 min

-1

1800 min

-1

0 - 8000 min

-1

0 - 28800 min

-1

13 mm

54 mm

13 mm

6 mm

60 Nm

2 - 13 mm

1,3 kg

1,7 kg

-18...+50 °C

L1840R, L1820R, L1820S

BL1218, BL18S

89,5 dB(A) / 5 dB(A)

100,5 dB(A) / 5 dB(A)

1,6 m/s

2

 / 1,5 m/s

2

8,1 m/s

2

 / 1,5 m/s

2

ENGLISH

TECHNICAL DATA

Type
Production code
Battery voltage
No-load speed 1st gear
No-load speed 2nd gear
Rate of percussion under load, 1st gear
Rate of percussion under load, 2st gear
Drilling capacity in steel
Drilling capacity in wood
Drilling capacity in brick and tile
Wood screws (without pre-drilling)
Torque max
Drill chuck range
Weight without battery
Weight according EPTA-Procedure 01/2014 (L1820S)
Recommended ambient operating temperature
Recommended battery types
Recommended charger

Noise Information:

Measured values determined according to

EN 62841.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level / Uncertainty K

Sound power level / Uncertainty K

Wear ear protectors!

Vibration Information:

Total vibration values (vector sum in the

three axes) determined according to EN 62841.

Vibration emission value a

h

/ Uncertainty K

Drilling into metal

Drilling into concrete

WARNING

  Read all safety warnings, instructions,

illustrations and specifications provided with this power

tool.

 Failure to follow all instructions listed below may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

DRILL SAFETY WARNINGS

Safety instructions for all operations

Wear ear protectors when impact drilling.

Exposure to noise

can cause hearing loss.

Hold the power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory may

contact hidden wiring.

Cutting accessory contacting a „live“

wire may make exposed metal parts of the power tool „live“ and

could give the operator an electric shock.

Safety instructions when using long drill bits

Never operate at higher speed than the maximum speed

rating of the drill bit.

 At higher speeds, the bit is likely to bend

if allowed to rotate freely without contacting the workpiece,

resulting in personal injury.

Always start drilling at low speed and with the bit tip in

contact with the workpiece.

At higher speeds, the bit is likely to

bend if allowed to rotate freely without contacting the workpiece,

resulting in personal injury.

Apply pressure only in direct line with the bit and do not

apply excessive pressure.

Bits can bend causing breakage or

loss of control, resulting in personal injury.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is

recommended, such as dust mask, protective gloves, sturdy

non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to

health. Do not inhale the dust. Wear a suitable dust protection

mask.
Do not machine any materials that present a danger to health

(e.g. asbestos).
Switch the device off immediately if the insertion tool stalls! Do

not switch the device on again while the insertion tool is stalled,

as doing so could trigger a sudden recoil with a high reactive

force. Determine why the insertion tool stalled and rectify this,

paying heed to the safety instructions.

WARNING

The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test

given in EN 62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration and noise emission may differ. This may significantly

increase the exposure level over the total working period.
An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration and/or noise such as: maintain the tool and the

accessories, keep the hands warm, organization of work patterns.

Cordless percussion drill/driver
