AEG BS18C2BL LI-402C 4935464095 - Инструкция по эксплуатации - Страница 10

18

19

BS18C2BL

BSB18C2BL

................................... 4674 89 01... ................................ 4674 98 01...

   ...000001-999999

   ...000001-999999

........................................ 13 mm .......................................... 13 mm

........................................ 40 mm .......................................... 40 mm

............................................   ................................................ 13 mm

.......................................... 6 mm ............................................ 6 mm

................................... 0-500 min

-1

 ................................... 0-500 min

-1

................................. 0-1950 min

-1

 ................................. 0-1950 min

-1

........................................... - min

-1

 ................................. 0-6500 min

-1

........................................... - min

-1

 ............................... 0-25350 min

-1

........................................ 60 Nm .......................................... 60 Nm

........................................ 65 Nm .......................................... 65 Nm

........................................ 18 V ............................................. 18 V

.................................. 1,5-13 mm .................................... 1,5-13 mm

....................................... 1,7 kg ........................................... 1,8 kg

....................................... 1,9 kg ........................................... 2,0 kg

................................................................... -18...+50 °C

................................................ L1840R, L1830R, L1820R, L1815R

...................................................................... BL1218

..................................... 87,5 dB (A)................................... 87,5 dB (A)

..................................... 98,5 dB (A)................................... 98,5 dB (A)

............................................   .................................................. 9 m/s

2

............................................   ............................................... 1,5 m/s

2

.................................... < 2,5 m/s

2

 ..................................... < 2,5 m/s

2

....................................... 1,5 m/s

2

 ........................................ 1,5 m/s

2

.................................... < 2,5 m/s

2

 ..................................... < 2,5 m/s

2

....................................... 1,5 m/s

2

 ........................................ 1,5 m/s

2

TECHNICAL DATA

CORDLESS PERCUSSION DRILL/DRIVER

Production code...............................................................................................

Drilling capacity in steel ...................................................................................

Drilling capacity in wood ..................................................................................

Drilling capacity in brick and tile ......................................................................

Wood screws (without pre-drilling) ..................................................................

No-load speed 1st gear ...................................................................................

No-load speed 2nd gear ..................................................................................

Impact rate 1st gear.........................................................................................

Impact rate 2nd gear .......................................................................................

Torque with battery (1.5 Ah / 2.0 Ah) *1 ...........................................................

Torque with battery (3.0 Ah / 4.0 Ah) *1 ...........................................................

Battery voltage.................................................................................................

Drill chuck range ..............................................................................................

Weight according EPTA-Procedure 01/2014 (1.5 Ah / 2.0 Ah) ........................

Weight according EPTA-Procedure 01/2014 (3.0 Ah / 4.0 Ah) ........................

Recommended ambient operating temperature ..............................................

Recommended battery types...........................................................................

Recommended charger ...................................................................................

Noise/vibration information

Measured values determined according to EN 60745.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A)) ................................................

Sound power level (Uncertainty K=3dB(A)) .....................................................

Always wear ear protectors!

Total vibration values (vector sum in the three axes) determined according to

EN 60745.

Vibration emission value a

h

  Percussion drilling into concrete a

h,ID

 ...........................................................

  Uncertainty K= .............................................................................................

  Drilling into metal a

h,D

 ...................................................................................

  Uncertainty K= .............................................................................................

  Screwing a

h

 ..................................................................................................

  Uncertainty K= .............................................................................................

*1 Measured according to AEG standard N 877318

 WARNING  Read all safety warnings, instructions, illustrations

and specifi cations provided with this power tool.

Failure to follow all

instructions listed below may result in electric shock, fi re and/or serious

injury.

Save all warnings and instructions for future reference.

DRILL SAFETY WARNINGS

Wear ear protectors when impact drilling.

Exposure to noise can cause

hearing loss.

Use auxiliary handle(s), if supplied with the tool.

Loss of control can

cause personal injury.

Brace the tool properly before use.

This tool produces a high output

torque and without properly bracing the tool during operation, loss of

control may occur resulting in personal injury.

Hold the power tool by insulated gripping surfaces, when performing

an operation where the cutting accessory may contact hidden wiring.

Cutting accessory contacting a "live" wire may make exposed metal parts

of the power tool "live" and could give the operator an electric shock.

Never operate at higher speed than the maximum speed rated of the

drill bit.

At higher speeds, the bit is likely to bend if allowed to rotate freely

without contacting the workpiece, resulting the personal injury.

Always start drilling at low speed and with the bit tip in contact with

the workpiece.

At higher speeds, the bit is likely to bend if allowed to

rotate freely without contacting the workpiece, resulting the personal injury.

Apply pressure only in direct line with the bit and do not apply

excessive pressure.

Bits can bend causing breakage or loss of control,

resulting in personal injury.

SCREWDRIVER SAFETY WARNINGS

Hold the power the tool by insulated gripping surfaces, when

performing an operation where the fastener may contact hidden

wiring.

Fasteners contacting a "live" wire may make exposed metal parts

of the power tool "live" and could give the operator an electric shock.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when working with

the machine. The use of protective clothing is recommended, such as dust

mask, protective gloves, sturdy non-slip footwear, helmet and ear

defenders.

The dust produced when using this tool may be harmful to health. Do not

inhale the dust. Wear a suitable dust protection mask.

Do not machine any materials that present a danger to health (e.g.

asbestos).

Switch the device off  immediately if the insertion tool stalls! Do not switch

the device on again while the insertion tool is stalled, as doing so could

trigger a sudden recoil with a high reactive force. Determine why the

insertion tool stalled and rectify this, paying heed to the safety instructions.

The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.

The insertion tool may become hot during use.

•  when changing tools

•  when setting the device down
Sawdust and splinters must not be removed while the machine is running.

When working in walls ceiling, or fl oor, take care to avoid electric cables

and gas or waterpipes.

Clamp your workpiece with a clamping device. Unclamped workpieces can

cause severe injury and damage.

Remove the battery pack before starting any work on the machine.

Do not dispose of used battery packs in the household refuse or by burning

them. AEG Distributors off er to retrieve old batteries to protect our

environment.

Do not store the battery pack together with metal objects (short circuit risk).

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and may be used to

compare one tool with another. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent applications, with diff erent

accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase the exposure level over the total working period.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off  or when it is running but not actually

doing the job. This may signifi cantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the accessories, keep the hands warm,

organisation of work patterns.

ENGLISH

Use only System GBS chargers for charging System GBS battery packs.

Do not use battery packs from other systems.

Never break open battery packs and chargers and store only in dry rooms.

Keep dry at all times.

Battery acid may leak from damaged batteries under extreme load or

extreme temperatures. In case of contact with battery acid wash it off

immediately with soap and water. In case of eye contact rinse thoroughly

for at least 10 minutes and immediately seek medical attention.

ALWAYS USE A SIDE HANDLE when using a 9.0 Ah or higher capacity

battery pack; the output torque of some tools may increase. If your drill/

driver did not come with a side handle, use the spare part side handle (see

explosion drawing of the tool).

Do not insert the bit on tool when the  tool is running, and switch is lock on

status, the bit will be run and may hurt the user

Warning!

To reduce the risk of fi re, personal injury, and product damage

due to a short circuit, never immerse your tool, battery pack or charger in

fl uid or al-low a fl uid to fl ow inside them. Corrosive or conductive fl uids,

such as seawater, certain industrial chemicals, and bleach or bleach

containing products, etc., Can cause a short circuit.

SPECIFIED CONDITIONS OF USE

The electronic battery percussion drill/screwdriver may be used for drilling,

percussion drilling, as well as screwdriving for independent use away from

mains supply.

Do not use this product in any other way as stated for normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product described under

“Technical Data” fulfi lls all the relevant regulations and the directives

2011/65/EU (RoHS), 2014/30/EU, 2006/42/EC, and the following

harmonized standards have been used:

EN 60745-1:2009 + A11:2010

EN 60745-2-1:2010

EN 60745-2-2:2010

EN 55014-1:2017

EN 55014-2:2015

EN 50581:2012

Winnenden, 2018-02-08

Alexander Krug

Managing Director

Authorized to compile the technical fi le.

Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should be

recharged before use.

Temperatures in excess of 50°C (122°F) reduce the performance of the

battery pack. Avoid extended exposure to heat or sunshine (risk of

overheating).

The contacts of chargers and battery packs must be kept clean.

For an optimum life-time, after use, the battery packs have to be fully

charged.

To obtain the longest possible battery life remove the battery pack from the

charger once it is fully charged.

For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and away from

moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION

In extremely high torque, binding, stalling and short circuit situations that

cause high current draw, the tool will vibrate for about 2 seconds and then

the tool will turn OFF.

To reset, release the trigger.

Under extreme circumstances, the internal temperatur of the battery could

become to high. If this happens, the battery will shut down.

Place the battery on the charger to charge and reset it.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods Legislation

requirements.

Transportation of those batteries has to be done in accordance with local,

national and international provisions and regulations.

•  The user can transport the batteries by road without further

requirements.

•  Commercial transport of Lithium-Ion batteries by third parties is subject to

Dangerous Goods regulations. Transport preparation and transport are

exclusively to be carried out by appropriately trained persons and the

process has to be accompanied by corresponding experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and insulated to

prevent short circuit.

•  Ensure that battery pack is secured against movement within packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

Use only AEG accessories and spare parts. Should components need to be

replaced which have not been described, please contact one of our AEG

service agents (see our list of guarantee/service addresses).

If needed, an exploded view of the tool can be ordered. Please state the

machine type printed as well as the six-digit No. on the label and order the

drawing at your local service agents or directly at: Techtronic Industries

GmbH, Max-Eyth-Straße 10, 71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work on the machine.

Please read the instructions carefully before starting the machine.

Do not dispose electric tools, batteries/rechargeable batteries together

with household waste material.

Electric tools and batteries that have reached the end of their life must

be collected separately and returned to an environmentally compatible

recycling facility.

Check with your local authority or retailer for recycling advice and

collection point.

n

0

No-load speed

V

Volts

Direct current

European Conformity Mark

Ukraine Conformity Mark

EurAsian Conformity Mark

ENGLISH
