4

ENGLISH

(Original instructions)

Explanation of general view

1

Shaft lock

2

Cover

3

Slide switch

4

Speed adjusting dial

5

Lever

6

Close

7

Open

8

Abrasive disc

9

Pad

10 Spindle
11 Exhaust vent
12 Inhalation vent

SPECIFICATION

• Due to our continuing program of research and devel-

opment, the specifications herein are subject to change
without notice.

• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003

ENE057-1

Intended use

The tool is intended for surface work with natural stone.

ENF002-2

Power supply

The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.

GEA010-1

General Power Tool Safety Warnings

WARNING Read all safety warnings and all

instructions.

Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and instructions for future reference.

GEB052-3

STONE POLISHER SAFETY WARNINGS

Safety Warnings Common for Polishing Operation:
1.

This power tool is intended to function as a pol-
isher. Read all safety warnings, instructions,
illustrations and specifications provided with
this power tool.

Failure to follow all instructions

listed below may result in electric shock, fire and/or
serious injury.

2.

Operations such as grinding, sanding, wire
brushing or cutting-off are not recommended to
be performed with this power tool.

Operations for

which the power tool was not designed may create a
hazard and cause personal injury.

3.

Do not use accessories which are not specifi-
cally designed and recommended by the tool
manufacturer.

Just because the accessory can be

attached to your power tool, it does not assure safe
operation.

4.

The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool.

Accessories running faster than

their rated speed can break and fly apart.

5.

The outside diameter and the thickness of your
accessory must be within the capacity rating of
your power tool.

Incorrectly sized accessories can-

not be adequately guarded or controlled.

6.

The arbour size of backing pads or any other
accessory must properly fit the spindle of the
power tool.

Accessories with arbour holes that do

not match the mounting hardware of the power tool
will run out of balance, vibrate excessively and may
cause loss of control.

7.

Do not use a damaged accessory. Before each
use inspect the accessory such as backing pad
for cracks. If power tool or accessory is dropped,
inspect for damage or install an undamaged
accessory. After inspecting and installing an
accessory, position yourself and bystanders
away from the plane of the rotating accessory
and run the power tool at maximum no-load
speed for one minute.

Damaged accessories will

normally break apar t during this test time.

8.

Wear personal protective equipment. Depending
on application, use face shield, safety goggles
or safety glasses. As appropriate, wear dust
mask, hearing protectors, gloves and workshop
apron capable of stopping small abrasive or
workpiece fragments.

The eye protection must be

capable of stopping flying debris generated by vari-
ous operations. The dust mask or respirator must be
capable of filtrating particles generated by your oper-
ation. Prolonged exposure to high intensity noise
may cause hearing loss.

9.

Keep bystanders a safe distance away from work
area. Anyone entering the work area must wear
personal protective equipment.

 Fragments of work-

piece or of a broken accessory may fly away and
cause injury beyond immediate area of operation.

10. Hold the power tool by insulated gripping sur-

faces only, when performing an operation where
the cutting accessory may contact hidden wiring
or its own cord.

 Cutting accessory contacting a

“live” wire may make exposed metal par ts of the
power tool “live” and could give the operator an elec-
tric shock.

11. Position the cord clear of the spinning acces-

sory.

If you lose control, the cord may be cut or

snagged and your hand or arm may be pulled into
the spinning accessory.

Model

PW5000C/PW5000CH

Spindle thread

M14

Pad diameter

Max. 125 mm

Rated speed (n) /

No load speed (n

0

)

2,000 – 4,400 min

–1

Overall length

313 mm

Net weight

2.3 kg

Safety class

/II
