9 ENGLISH

Installing or removing wheel guard

(For depressed center wheel,

multi disc / abrasive cut-off wheel,

diamond wheel)

For tool with locking screw type

wheel guard

►

Fig.4:

1.

 Wheel guard

2.

 Screw

3.

 Bearing box

WARNING:

•

When using a depressed center grinding wheel/

Multi-disc, flex wheel, wire wheel brush, cut-off

wheel or diamond wheel, the wheel guard must

be fitted on the tool so that the closed side of the

guard always points toward the operator.

•

When using an abrasive cut-off / diamond

wheel, be sure to use only the special wheel

guard designed for use with cut-off wheels. (In

European countries, when using a diamond

wheel, the ordinary guard can be used.)

Mount the wheel guard with the protrusion on the wheel guard

band aligned with the notch on the bearing box. Then rotate

the wheel guard to such an angle that it can protect the opera-

tor according to work. Be sure to tighten the screw securely.

To remove wheel guard, follow the installation proce-

dure in reverse.

For tool with clamp lever type wheel guard

►

Fig.5:

1.

 Wheel guard

2.

 Bearing box

3.

 Screw

4.

 Lever

►

Fig.6:

1.

 Screw

2.

 Lever

Loosen the lever on the wheel guard after loosening the screw.

Mount the wheel guard with the protrusion on the wheel guard

band aligned with the notch on the bearing box. Then rotate

the wheel guard around to the position shown in the figure.

Tighten the lever to fasten the wheel guard. If the lever is too

tight or too loose to fasten the wheel guard, loosen or tighten

the screw to adjust the tightening of the wheel guard band.

To remove wheel guard, follow the installation procedure in reverse.

Installing or removing depressed

center grinding wheel/Multi-disc

►

Fig.7:

1.

 Lock nut

2.

 Depressed center grinding

wheel/Multi-disc

3.

 Inner flange

WARNING:

•

Always use supplied guard when depressed

center grinding wheel/Multi-disc is on tool.

Wheel can shatter during use and guard helps

to reduce chances of personal injury.

Mount the inner flange onto the spindle. Fit the wheel/disc

on the inner flange and screw the lock nut onto the spindle.

To tighten the lock nut, press the shaft lock firmly so

that the spindle cannot revolve, then use the lock nut

wrench and securely tighten clockwise.

►

Fig.8:

1.

 Lock nut wrench

2.

 Shaft lock

To remove the wheel, follow the installation procedure in reverse.

WARNING:

 Only actuate the shaft lock when the

spindle is not moving.

OPERATION

WARNING:

•

It should never be necessary to force the tool.

The weight of the tool applies adequate pres

-

sure. Forcing and excessive pressure could

cause dangerous wheel breakage.

•

ALWAYS replace wheel if tool is dropped while

grinding.

•

NEVER bang or hit grinding disc or wheel onto

work.

•

Avoid bouncing and snagging the wheel, espe

-

cially when working corners, sharp edges etc.

This can cause loss of control and kickback.

•

NEVER use tool with wood cutting blades and

other saw blades. Such blades when used on a

grinder frequently kick and cause loss of control

leading to personal injury.

CAUTION:

•

After operation, always switch off the tool and

wait until the wheel has come to a complete stop

before putting the tool down.

Grinding and sanding operation

ALWAYS hold the tool firmly with one hand on housing

and the other on the side handle. Turn the tool on and

then apply the wheel or disc to the workpiece.

In general, keep the edge of the wheel or disc at an

angle of about 15 degrees to the workpiece surface.

During the break-in period with a new wheel, do not

work the grinder in the B direction or it will cut into

the workpiece. Once the edge of the wheel has been

rounded off by use, the wheel may be worked in both A

and B direction.

►

Fig.9
