 English |

13

Bosch Power Tools

1 619 X07 388 | (19.3.12)

Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:

Sound pressure level 93 dB(A); Sound power level

104 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

a

h

= 3.5 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

sure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

riod.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents: EN 60745

according to the provisions of the directives 2011/65/EU,

2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:

Robert Bosch GmbH, PT/ETM9,

D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

29.02.2012

Assembly

f

Before any work on the machine itself, pull the mains

plug.

Dust/Chip Extraction

f

Dusts from materials such as lead-containing coatings,

some wood types, minerals and metal can be harmful to

one’s health. Touching or breathing-in the dusts can cause

allergic reactions and/or lead to respiratory infections of

the user or bystanders.

Certain dusts, such as oak or beech dust, are considered

as carcinogenic, especially in connection with wood-treat-

ment additives (chromate, wood preservative). Materials

containing asbestos may only be worked by specialists.

– As far as possible, use a dust extraction system suita-

ble for the material.

– Provide for good ventilation of the working place.

– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the

materials to be worked.

f

Prevent dust accumulation at the workplace.

Dusts can

easily ignite.

Integrated Dust Extraction with Dust Box

(see Fig. A1 – A4)

Mount the extraction adapter

9

 onto the extraction outlet

10

.

Mount the dust box

6

 onto the extraction adapter

9

, ensuring

that it engages.
To empty the dust box

6

, press the latching levers

11

 on the

side of the dust box. Pull off the dust box.
Before opening the dust box

6

, it is recommended to loosen

the dust from the filter element by gently striking it against a

firm support (as shown in the figure).
Grasp the dust box

6

 by the recessed grip, fold the filter ele-

ment

12

 upward and empty the dust box. Clean the thin

plates of the filter element

12

 with a soft brush.

Note:

The belt sander has a high removal rate. To ensure op-

timum dust extraction, empty the dust box

6

 regularly after

5 minutes of operation and clean the filter element

12

 regu-

larly.

External Dust Extraction

Mount a vacuum hose  onto the extraction outlet

10

. Connect

the vacuum hose  with a vacuum cleaner. An overview for the

connection of various vacuum cleaners can be found at the

end of these instructions.
The vacuum cleaner must be suitable for the material being

worked.
When vacuuming dry dust that is especially detrimental to

health or carcinogenic, use a special vacuum cleaner.

Changing the Sanding Belt (see figures B – D)

– Completely pivot out the clamping lever

3

. The sanding

belt

2

 is now loose and can be removed.

– Mount the new sanding belt

2

. Pay attention that the direc-

tion of the arrows on the inside of the sanding belt corre-

spond with the arrow direction on the machine housing.

– Pivot the clamping lever

3

 back to its initial position.

– Pick up the machine and switch it on. The belt run is auto-

matically centred upon switching on and during the sand-

ing procedure.

If the sanding belt is not centred after switching on the ma-

chine, the belt run must be readjusted manually, if required.

For this, readjust adjustment screw

13

 at the front roll using a

screwdriver until the sanding belt

2

 runs in a position with dis-

tance of about 2 – 3 mm between the belt and the aluminium

housing, see figure D. Should the belt run still not be centred

after this, then the sanding belt

2

 must be replaced.

Dr. Egbert Schneider

Senior Vice President

Engineering

Helmut Heinzelmann

Head of Product Certification

PT/ETM9
