12

 | English

1 619 X07 388 | (19.3.12)

Bosch Power Tools

f

Pay attention that no persons are put at risk through

sparking. Remove any combustible materials in the vi-

cinity.

Sparking occurs when sanding metal materials.

f

Do not use worn, torn or heavily clogged sanding belts.

Damaged sanding belts can tear apart, be thrown from the

machine and injure somebody.

f

Caution, fire hazard! Avoid overheating the object be-

ing sanded as well as the sander. Always empty the

dust collector before taking breaks.

In unfavourable

conditions, e. g., when sparks emit from sanding metals,

sanding debris in the dust bag, micro filter or paper sack

(or in the filter sack or filter of the vacuum cleaner) can

self-ignite. Particularly when mixed with remainders of var-

nish, polyurethane or other chemical materials and when

the sanding debris is hot after long periods of working.

f

Regularly clean the power tool’s air vents.

The motor’s

fan will draw the dust inside the housing and excessive ac-

cumulation of powdered metal may cause electrical haz-

ards.

f

When working with the machine, always hold it firmly

with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.

f

Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

f

Always wait until the machine has come to a complete

stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.

Products sold in GB only

: Your product is fitted with an

BS 1363/A approved electric plug with internal fuse (ASTA

approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an author-

ised customer service agent. The replacement plug should

have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains sock-

et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

Intended Use

The machine is intended for dry sanding – with high removal

capacity – of wood, plastic, metal, filler as well as varnished

surfaces.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1

Auxiliary handle (insulated gripping surface)

2

Sanding belt *

3

Clamping lever for sanding belt

4

Thumbwheel for belt speed preselection (PBS 75 AE)

5

On/Off switch

6

Dust box, complete (Microfilter System)

7

Lock-on button for On/Off switch

8

Handle (insulated gripping surface)

9

Extraction adapter

10

Extraction outlet

11

Latching lever for dust box

12

Filter element (Microfilter System)

13

Adjustment screw for belt run

14

Protection cover

15

Dust passage

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Belt Sander

PBS 75 A

PBS 75 AE

Article number

3 603 BA1 0..

3 603 BA1 1..

Rated power input

W

710

750

No-load belt speed

m/min

350

200 – 350

Sanding belt length

mm

533

533

Sanding belt width

mm

75

75

Belt speed preselection

–

z

Connection for internal/external dust extraction

z

z

Weight according to EPTA-Procedure 01/2003

kg

3.4

3.5

Protection class

/

II

/

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
