Dust/Chip Extraction

f

Dusts from materials such as lead-containing
coatings, some wood types, minerals and
metal can be harmful to one’s health. Touch-
ing or breathing-in the dusts can cause aller-
gic reactions and/or lead to respiratory infec-
tions of the user or bystanders.
Certain dusts, such as oak or beech dust, are
considered as carcinogenic, especially in
connection with wood-treatment additives
(chromate, wood preservative). Materials
containing asbestos may only be worked by
specialists.

–

Use dust extraction whenever possible.

–

Provide for good ventilation of the work-
ing place.

–

It is recommended to wear a P2 filter-
class respirator.

Observe the relevant regulations in your
country for the materials to be worked.

Integrated Dust Extraction with Dust Box
(see figures C1 – C4)

Before assembling the dust box

6

, pull out the

plastic slider

12

. Place the dust box

6

 onto the

extraction outlet

13

 and allow it to engage.

Make sure that the plastic slider

12

 engages in

the holder

11

.

To empty the dust box

6

, press the latching

levers

14

 on the side of the dust box (

n

). Pull

off the dust box toward the bottom (

o

).

Before opening the dust box

6

, it is recommend-

ed to loosen the dust from the filter element by
gently striking it against a firm support (as
shown in the figure).
Grasp the dust box

6

 by the recessed grip, fold

the filter element

15

 upward and empty the dust

box. Clean the thin plates of the filter element

15

 with a soft brush.

External Dust Extraction (see figure D)

Slide the extraction adapter

16

 onto the outlet

piece

13

. Ensure that the latching levers of the

extraction adapter engage. The extraction
adapter

16

 accepts a vacuum hose with a diam-

eter of 19 mm.

For removal of the extraction adapter

16

, press

the latching levers together at the rear and pull
the extraction adapter off.
The vacuum cleaner must be suitable for the ma-
terial being worked.
When vacuuming dry dust that is especially det-
rimental to health or carcinogenic, use a special
vacuum cleaner.

Internal Dust Extraction with Dust Bag
(see figure E)

For small sanding jobs, a dust bag (accessory)

18

 can be connected.

Before mounting the dust bag

18

, pull out the

plastic slider

12

. Slide the dust-bag sleeve firmly

over the extraction outlet

13

. Pay attention that

the plastic slider

12

 engages in the holder in-

tended for it on the dust bag

18

.

To maintain optimum dust collection, empty the
dust bag

18

 in good time.

Auxiliary Handle

The auxiliary handle

1

 enables convenient han-

dling and optimal distribution of power, espe-
cially at high removal rates.
Fasten the auxiliary handle

1

 with screw

2

 to the

casing.

Operation

Starting Operation

f

Observe correct mains voltage! The voltage
of the power source must agree with the
voltage specified on the nameplate of the
machine. Power tools marked with 230 V
can also be operated with 220 V.

Switching On and Off

To

start

 the machine, press the On/Off switch

4

and keep it pressed.
To lock the

pressed

 On/Off switch

4

, press the

lock-on button

5

.

To

switch off

 the machine, release the On/Off

switch

4

 or when it is locked with the lock-on

button

5

, briefly press the On/Off switch

4

 and

then release it.
