 English |

17

Bosch Power Tools

1 609 92A 29F | (21.7.16)



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

Observe the notes for disposal.

Removing the battery (see figure A)

To remove the battery

4

 press the unlocking buttons

5

 and

pull out the battery downwards.

Do not exert any force.

Battery Charge-control Indication

Mounting the Protective Devices



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.

Note:

After breakage of the grinding disc during operation or

damage to the holding fixtures on the protection guard/power
tool, the machine must promptly be sent to an after-sales ser-
vice agent for maintenance. For addresses, see section “Af-
ter-sales Service and Application Service”.

Protection Guard for Cutting



For cutting with bonded abrasives, always use the pro-
tection guard for cutting 10.



Provide for sufficient dust extraction when cutting
stone.

Mounting the blade guard (see figure B)

The protection guard for cutting

10

 is mounted onto the pro-

tection guard for grinding

7

 until it engages.

Adjusting the Protection Guard

Turn the protection guard to the desired position until it en-
gages. No tool is required for this.

Mounting the Grinding Tools (see figure B)



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.



Do not touch grinding and cutting discs before they
have cooled down.

The discs can become very hot while

working.

Clean the grinder spindle

8

 and all parts to be mounted.

For tightening or loosening the grinding tools, push the spin-
dle lock button

2

 forwards and simultaneously turn the grind-

ing tool to fix the grinder spindle.



Actuate the spindle lock button only when the grinder
spindle is at a standstill.

Otherwise, the machine may be-

come damaged.

Grinding/Cutting Disc

Pay attention to the dimensions of the grinding tools. The
mounting hole diameter must fit the mounting flange without
play. Do not use reducers or adapters.

When using diamond cutting discs, pay attention that the di-
rection-of-rotation arrow on the diamond cutting disc and the
direction of rotation of the machine (see direction-of-rotation
arrow on the housing) agree.

See graphics page for the mounting sequence.

Attach the grinding tool using the bolt

11

. Tighten the bolt us-

ing the hex key

13

 until the washer of the bolt is flush with the

grinding tool.



After mounting the grinding tool and before switching
on, check that the grinding tool is correctly mounted
and that it can turn freely. Make sure that the grinding
tool does not graze against the protection guard or oth-
er parts.

Approved Grinding Tools

All grinding tools mentioned in these operating instructions
can be used.

The permissible speed [min

-1

] or the circumferential speed

[m/s] of the grinding tools used must at least match the values
given in the table.

Therefore, observe the permissible

rotational/circumferen-

tial speed

 on the label of the grinding tool.

Selecting Grinding Discs

Dust/Chip Extraction



Dust from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dust can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dust, such as oak or beech dust, is considered car-
cinogenic, especially in connection with wood-treatment
additives (chromate, wood preservative). Materials con-
taining asbestos may only be worked by specialists.

LED

Capacity

Continuous lighting 3 x green

≥

2/3

Continuous lighting 2 x green

≥

1/3

Continuous lighting 1 x green

< 1/3

Flashing light 1 x green

Reserve

max.

[mm]

[mm]

D

b

d

[min

-1

]

[m/s]

76

7

10

19 500

80

Grinding discs

Material

Carbide Multi Wheel

PVC, wood,
composites,
acrylic glass

Expert for Inox

Aluminium,
copper

Best for Ceramic

Tile, concrete,
brick
