ENGLISH

en

10

substances: ensure good ventilation of the

workplace and wear appropriate protective

equipment, such as respirators able to filter

microscopically small particles.
Observe the relevant guidelines for your material,

staff, application and place of application (e.g.

occupational health and safety regulations,

disposal).
Collect the generated particles at the source, avoid

deposits in the surrounding area.
Use suitable accessories for special work, thus less

particles enter the environment in an uncontrolled

manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:

- Do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits.

- Use an extraction unit and/or air purifiers.

- Ensure good ventilation of the workplace and

keep clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

Transport of li-ion battery packs:

The shipping of li-ion battery pack is subject to laws

related to the carriage of hazardous goods (UN

3480 and UN 3481). Inform yourself of the currently

valid specifications when shipping li-ion battery

packs. If necessary, consult your freight forwarder.

Certified packaging is available from Metabo.
Only send the battery pack if the housing is intact

and no fluid is leaking. Remove the battery pack

from the machine for sending. Prevent the contacts

from short-circuiting (e.g. by protecting them with

adhesive tape).

See page 2.

1 Depot for hexagon wrench

2 Hexagon wrench

3 Screw for setting the guide

4 Guide

5 Saw blade quick-clamping device

6 Lever for saw blade quick-clamping device

7 Front handle

8 Switch-on locking button

9 Trigger

10 Rear handle

11 Battery pack release

12 Battery pack

13 Capacity indicator button

14 Capacity and signal indicator

Remove the battery pack from the machine before

any adjustment or maintenance is carried out.

6.1 Battery pack

Charge the battery pack before use (12).
If performance diminishes, recharge the battery

pack.

"Li-Power"

li-ion battery packs

have a capacity

and signal indicator: (14)

- Press the  (13) button, the LEDs indicate the

charge level.

- If one LED is flashing, the battery pack is almost

flat and must be recharged.

Removal:

Press the battery pack release  (11) button and pull

the battery pack (12) forwards.

Inserting:

Slide in the battery pack (12) until it engages.

6.2 Inserting, removing saw blade

Do not touch the saw blade immediately

following operation of the tool, as it can be

extremely hot and can lead to skin burns.

1 Pull up lever (6) of saw blade quick-clamping

device upwards and hold in this position.

2 Insert the saw blade as far as it will go or remove

it.

3 Release lever (6).

4 Check that the saw blade is securely seated.

Note:

If a saw blade happens to break off and

cannot be removed by hand from the saw blade

quick-clamping device, pull up lever (6) and hold.

Engage the tip of a saw blade in the broken section

and pull it out. A fine-toothed metal saw blade is

best suited for this task. See Fig. A, page 2.

Tip:

 The best possible access to the saw blade

quick-clamping device (5) is achieved when it is in

its outermost position. If necessary: switch of the

machine, press the trigger switch (9) lightly to move

the saw blade quick-clamping device into its

outermost position.

6.3 Setting the guide

The cutting depth can be limited by shifting the

guide (4) (e.g. when sawing in front of a wall).

Occasionally shift the guide (4) to achieve even

wear of the saw blade.

1 Remove hexagon wrench (2) from its depot (1).
2 Release both screws (3) with hexagon wrench.
3 Shift guide (4) to desired position.
4 Tighten both screws (3) again with hexagon

wrench.

5 Insert hexagon wrench for safekeeping in its

depot.

Check guide for correct seating.

7.1 Switching on and off

Switching on:

Press switch-on locking button (8)

and hold in; then actuate the trigger (9).

5. Overview

6. Assembly, Initial Operation,

Setting

7. Use
