14

 | English

1 609 92A 4JX | (01.10.2018)

Bosch Power Tools

Reciprocating saw

AdvancedRecip 18

Tool holder

SDS

Stroke

mm

23

Max. cutting depth

– in wood

mm

100

– in steel (unalloyed)

mm

20

– Pipe diameter

mm

20

Weight according to
EPTA-Procedure 01:2014

kg

2.1

Weight with 2.5 Ah battery
(PBA 18  2,5 Ah) according
to EPTA-Procedure
01:2014

kg

2.5

Permitted ambient temperature

– during charging

°C

0 to +45

– during operation

A)

 and

during storage

°C

−20 to +50

Recommended batteries

PBA 18V...V -.

PBA 18V...W-.

Recommended chargers

AL 22.. CV
AL 18.. CV

A)

Limited performance at temperatures <0 °C

Noise/vibration information

Noise emission values determined according to

EN 62841-2-11

.

Typically, the A-weighted noise level of the power tool is:

Sound pressure level

86

 dB(A); sound power level

97

 dB(A). Uncertainty K=

5

 dB.

Wear hearing protection

Total vibration values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-11

:

Cutting boards with saw blade S 3456 XF:
a

h,B

=

10

 m/s

2

, K=

1.5

 m/s

2

;

Cutting wooden beams with saw blade S 3456 XF:
a

h,WB

=

10.5

 m/s

2

, K=

1.5

 m/s

2

.

The vibration level and noise emission value given in these

instructions have been measured in accordance with a

standardised measuring procedure

 detailed in EN 62841

and may be used to com-pare power tools. They may also be
used for a preliminary

estimation of vibration and noise

emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the

power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level

and noise emission value may differ. This may significantly

increase the vibration and noise emissions over the total

working period.
To estimate vibration and noise emissions accurately, the

times when the tool is switched off or when it is running but

not actually being used should also be taken into account.

This may significantly reduce vibration and noise emissions

over the total working period.

Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.

Fitting

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

Charging the battery (see figure B)

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your power tool.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.

u

Do not continue to press the On/Off switch after the
power tool has automatically switched off.

 The battery

can be damaged.

To remove the battery

(8)

, press the release button

(10)

and pull the battery back and out of the power tool.

Do not

use force to do this.

Battery charge-control indicator

When the on/off switch

(6)

 is pressed in halfway or com-

pletely, the battery charge indicator

(5)

 indicates the bat-

tery's state of charge for several seconds. The indicator con-
sists of three green LEDs.

LED

Capacity

Continuous light 3 x green

> 66%

Continuous light 2 x green

33–66%

Continuous light 1 x green

11–33%

Slowly flashing light 1 x green

<11%

The 3 LEDs in the battery charge indicator

(5)

 flash quickly if

the temperature of the battery is above the permitted oper-
ating temperature range.

Inserting/changing the saw blade

u

When fitting or changing the saw blade, wear protect-
ive gloves.

 Blades are sharp and can become hot when

used for prolonged periods of time.

u

While replacing the saw blade, ensure that the saw
blade receptacle is free of material residue, e.g. wood
or metal chips.
